Deploy an external multi-cluster Gateway

This document guides you through a practical example to deploy an external multi-cluster Gateway to route internet traffic to an application that runs in two different GKE clusters.

Multi-cluster Gateways provide a powerful way to manage traffic for services deployed across multiple GKE clusters. By using Google's global load-balancing infrastructure, you can create a single entry point for your applications, which simplifies management and improves reliability.

In this tutorial, you use a sample store application to simulate a real-world scenario where an online shopping service is owned and operated by separate teams and deployed across a fleet of shared GKE clusters.

This example shows you how to set up path-based routing to direct traffic to different clusters.

Before you begin

Multi-cluster Gateways require some environmental preparation before they can be deployed. Before you proceed, follow the steps in Prepare your environment for multi-cluster Gateways:

  1. Deploy GKE clusters.

  2. Register your clusters to a fleet (if they aren't already).

  3. Enable the multi-cluster Service and multi-cluster Gateway controllers.

Finally, review the GKE Gateway controller limitations and known issues before you use the controller in your environment.

Multi-cluster, multi-region, external Gateway

In this tutorial, you create an external multi-cluster Gateway that serves external traffic across an application running in two GKE clusters.

store.example.com is deployed across two GKE clusters and exposed to the internet using a multi-cluster Gateway

In the following steps you:

  1. Deploy the sample store application to the gke-west-1 and gke-east-1 clusters.
  2. Configure Services on each cluster to be exported into your fleet (multi-cluster Services).
  3. Deploy an external multi-cluster Gateway and an HTTPRoute to your config cluster (gke-west-1).

After the application and Gateway resources are deployed, you can control traffic across the two GKE clusters using path-based routing:

  • Requests to /west are routed to store Pods in the gke-west-1 cluster.
  • Requests to /east are routed to store Pods in thegke-east-1 cluster.
  • Requests to any other path are routed to either cluster, according to its health, capacity, and proximity to the requesting client.

Deploying the demo application

  1. Create the store Deployment and Namespace in all three of the clusters that were deployed in Prepare your environment for multi-cluster Gateways:

    kubectl apply --context gke-west-1 -f https://raw.githubusercontent.com/GoogleCloudPlatform/gke-networking-recipes/main/gateway/gke-gateway-controller/multi-cluster-gateway/store.yaml
kubectl apply --context gke-west-2 -f https://raw.githubusercontent.com/GoogleCloudPlatform/gke-networking-recipes/main/gateway/gke-gateway-controller/multi-cluster-gateway/store.yaml
kubectl apply --context gke-east-1 -f https://raw.githubusercontent.com/GoogleCloudPlatform/gke-networking-recipes/main/gateway/gke-gateway-controller/multi-cluster-gateway/store.yaml

    It deploys the following resources to each cluster:

    namespace/store created
deployment.apps/store created

    All examples in this page use the app deployed in this step. Make sure that the app is deployed across all three clusters before trying any of the remaining steps. This example uses only clusters gke-west-1 and gke-east-1 , and gke-west-2 is used in another example.

Multi-cluster Services

Services are how Pods are exposed to clients. Because the GKE Gateway controller uses container-native load balancing, it does not use the ClusterIP or Kubernetes load balancing to reach Pods. Traffic is sent directly from the load balancer to the Pod IP addresses. However, Services still play a critical role as a logical identifier for Pod grouping.

Multi-cluster Services (MCS) is an API standard for Services that span clusters and its GKE controller provides service discovery across GKE clusters. The multi-cluster Gateway controller uses MCS API resources to group Pods into a Service that is addressable across or spans multiple clusters.

The multi-cluster Services API defines the following custom resources:

  • ServiceExports map to a Kubernetes Service, exporting the endpoints of that Service to all clusters registered to the fleet. When a Service has a corresponding ServiceExport it means that the Service can be addressed by a multi-cluster Gateway.
  • ServiceImports are automatically generated by the multi-cluster Service controller. ServiceExport and ServiceImport come in pairs. If a ServiceExport exists in the fleet, then a corresponding ServiceImport is created to allow the Service mapped to the ServiceExport to be accessed from across clusters.

Exporting Services works in the following way. A store Service exists in gke-west-1 which selects a group of Pods in that cluster. A ServiceExport is created in the cluster which lets the Pods in gke-west-1 become accessible from the other clusters in the fleet. The ServiceExport maps to and exposes Services that have the same name and Namespace as the ServiceExport resource.

apiVersion: v1
kind: Service
metadata:
  name: store
  namespace: store
spec:
  selector:
    app: store
  ports:
  - port: 8080
    targetPort: 8080
---
kind: ServiceExport
apiVersion: net.gke.io/v1
metadata:
  name: store
  namespace: store

The following diagram shows what happens after a ServiceExport is deployed. If a ServiceExport and Service pair exist then the multi-cluster Service controller deploys a corresponding ServiceImport to every GKE cluster in the fleet. The ServiceImport is the local representation of the store Service in every cluster. This enables the client Pod in gke-east-1 to use ClusterIP or headless Services to reach the store Pods in gke-west-1. When used in this manner multi-cluster Services provide east-west load balancing between clusters without requiring an internal LoadBalancer Service. To use multi-cluster Services for cluster-to-cluster load balancing, see Configuring multi-cluster Services.

Multi-cluster Services exports Services across clusters which allows cluster-to-cluster communication

Multi-cluster Gateways also use ServiceImports, but not for cluster-to-cluster load balancing. Instead, Gateways use ServiceImports as logical identifiers for a Service that exists in another cluster or that stretches across multiple clusters. The following HTTPRoute references a ServiceImport instead of a Service resource. By referencing a ServiceImport, this indicates that it is forwarding traffic to a group of backend Pods that run across one or more clusters.

kind: HTTPRoute
apiVersion: gateway.networking.k8s.io/v1
metadata:
  name: store-route
  namespace: store
  labels:
    gateway: multi-cluster-gateway
spec:
  parentRefs:
  - kind: Gateway
    namespace: store
    name: external-http
  hostnames:
  - "store.example.com"
  rules:
  - backendRefs:
    - group: net.gke.io
      kind: ServiceImport
      name: store
      port: 8080

The following diagram shows how the HTTPRoute routes store.example.com traffic to store Pods on gke-west-1 and gke-east-1. The load balancer treats them as one pool of backends. If the Pods from one of the clusters becomes unhealthy, unreachable, or has no traffic capacity, then traffic load is balanced to the remaining Pods on the other cluster. New clusters can be added or removed with the store Service and ServiceExport. This transparently adds or removes backend Pods without any explicit routing configuration changes.

MCS resource

Exporting Services

At this point, the application is running across both clusters. Next, you expose and export the applications by deploying Services and ServiceExports to each cluster.

  1. Apply the following manifest to the gke-west-1 cluster to create your store and store-west-1 Services and ServiceExports:

    cat << EOF | kubectl apply --context gke-west-1 -f -
apiVersion: v1
kind: Service
metadata:
  name: store
  namespace: store
spec:
  selector:
    app: store
  ports:
  - port: 8080
    targetPort: 8080
---
kind: ServiceExport
apiVersion: net.gke.io/v1
metadata:
  name: store
  namespace: store
---
apiVersion: v1
kind: Service
metadata:
  name: store-west-1
  namespace: store
spec:
  selector:
    app: store
  ports:
  - port: 8080
    targetPort: 8080
---
kind: ServiceExport
apiVersion: net.gke.io/v1
metadata:
  name: store-west-1
  namespace: store
EOF

  2. Apply the following manifest to the gke-east-1 cluster to create your store and store-east-1 Services and ServiceExports:

    cat << EOF | kubectl apply --context gke-east-1 -f -
apiVersion: v1
kind: Service
metadata:
  name: store
  namespace: store
spec:
  selector:
    app: store
  ports:
  - port: 8080
    targetPort: 8080
---
kind: ServiceExport
apiVersion: net.gke.io/v1
metadata:
  name: store
  namespace: store
---
apiVersion: v1
kind: Service
metadata:
  name: store-east-1
  namespace: store
spec:
  selector:
    app: store
  ports:
  - port: 8080
    targetPort: 8080
---
kind: ServiceExport
apiVersion: net.gke.io/v1
metadata:
  name: store-east-1
  namespace: store
EOF

  3. Verify that the correct ServiceExports have been created in the clusters.

    kubectl get serviceexports --context CLUSTER_NAME --namespace store

    Replace CLUSTER_NAME with gke-west-1 and gke-east-1. The output resembles the following:

    # gke-west-1
NAME           AGE
store          2m40s
store-west-1   2m40s

# gke-east-1
NAME           AGE
store          2m25s
store-east-1   2m25s

    The output demonstrates that the store Service contains store Pods across both clusters, and the store-west-1 and store-east-1 Services only contain store Pods on their respective clusters. These overlapping Services are used to target the Pods across multiple clusters or a subset of Pods on a single cluster.

  4. After a few minutes verify that the accompanying ServiceImports have been automatically created by the multi-cluster Services controller across all clusters in the fleet.

    kubectl get serviceimports --context CLUSTER_NAME --namespace store

    Replace CLUSTER_NAME with gke-west-1 and gke-east-1. The output should resemble the following:

    # gke-west-1
NAME           TYPE           IP                  AGE
store          ClusterSetIP   ["10.112.31.15"]    6m54s
store-east-1   ClusterSetIP   ["10.112.26.235"]   5m49s
store-west-1   ClusterSetIP   ["10.112.16.112"]   6m54s

# gke-east-1
NAME           TYPE           IP                  AGE
store          ClusterSetIP   ["10.72.28.226"]    5d10h
store-east-1   ClusterSetIP   ["10.72.19.177"]    5d10h
store-west-1   ClusterSetIP   ["10.72.28.68"]     4h32m

    This demonstrates that all three Services are accessible from both clusters in the fleet. However, because there is only a single active config cluster per fleet, you can only deploy Gateways and HTTPRoutes that reference these ServiceImports in gke-west-1. When an HTTPRoute in the config cluster references these ServiceImports as backends, the Gateway can forward traffic to these Services no matter which cluster they are exported from.

Deploying the Gateway and HTTPRoute

Once the applications have been deployed, you can then configure a Gateway using the gke-l7-global-external-managed-mc GatewayClass. This Gateway creates an external Application Load Balancer configured to distribute traffic across your target clusters.

  1. Apply the following Gateway manifest to the config cluster, gke-west-1 in this example:

    cat << EOF | kubectl apply --context gke-west-1 -f -
kind: Gateway
apiVersion: gateway.networking.k8s.io/v1
metadata:
  name: external-http
  namespace: store
spec:
  gatewayClassName: gke-l7-global-external-managed-mc
  listeners:
  - name: http
    protocol: HTTP
    port: 80
    allowedRoutes:
      kinds:
      - kind: HTTPRoute
EOF

    This Gateway configuration deploys external Application Load Balancer resources with the following naming convention: gkemcg1-NAMESPACE-GATEWAY_NAME-HASH.

    The default resources created with this configuration are:

    • 1 load balancer: gkemcg1-store-external-http-HASH
    • 1 public IP address: gkemcg1-store-external-http-HASH
    • 1 forwarding rule: gkemcg1-store-external-http-HASH
    • 2 backend services:
      • Default 404 backend service: gkemcg1-store-gw-serve404-HASH
      • Default 500 backend service: gkemcg1-store-gw-serve500-HASH
    • 1 Health check:
      • Default 404 health check: gkemcg1-store-gw-serve404-HASH
    • 0 routing rules (URLmap is empty)

    At this stage, any request to the GATEWAY_IP:80 results in a default page displaying the following message: fault filter abort.

  2. Apply the following HTTPRoute manifest to the config cluster, gke-west-1 in this example:

    cat << EOF | kubectl apply --context gke-west-1 -f -
kind: HTTPRoute
apiVersion: gateway.networking.k8s.io/v1
metadata:
  name: public-store-route
  namespace: store
  labels:
    gateway: external-http
spec:
  hostnames:
  - "store.example.com"
  parentRefs:
  - name: external-http
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /west
    backendRefs:
    - group: net.gke.io
      kind: ServiceImport
      name: store-west-1
      port: 8080
  - matches:
    - path:
        type: PathPrefix
        value: /east
    backendRefs:
      - group: net.gke.io
        kind: ServiceImport
        name: store-east-1
        port: 8080
  - backendRefs:
    - group: net.gke.io
      kind: ServiceImport
      name: store
      port: 8080
EOF

    At this stage, any request to the GATEWAY_IP:80 results in a default page displaying the following message: fault filter abort.

    After deployment, this HTTPRoute configures the following routing behavior:

    • Requests to /west are routed to store Pods in the gke-west-1 cluster, because Pods selected by the store-west-1 ServiceExport only exist in the gke-west-1 cluster.
    • Requests to /east are routed to store Pods in thegke-east-1 cluster, because Pods selected by the store-east-1 ServiceExport only exist in the gke-east-1 cluster.
    • Requests to any other path are routed to store Pods in either cluster, according to its health, capacity, and proximity to the requesting client.
    • Requests to the GATEWAY_IP:80 results in a default page displaying the following message: fault filter abort.

    The HTTPRoute enables routing to different subsets of clusters by using overlapping Services

    Note that if all the Pods on a given cluster are unhealthy (or don't exist) then traffic to the store Service would only be sent to clusters that actually have store Pods. The existence of a ServiceExport and Service on a given cluster does not guarantee that traffic is sent to that cluster. Pods must exist and respond affirmatively to the load balancer health check or else the load balancer just sends traffic to healthy store Pods in other clusters.

    New resources are created with this configuration:

    • 3 backend services:
      • The store backend service: gkemcg1-store-store-8080-HASH
      • The store-east-1 backend service: gkemcg1-store-store-east-1-8080-HASH
      • The store-west-1 backend service: gkemcg1-store-store-west-1-8080-HASH
    • 3 Health checks:
      • The store health check: gkemcg1-store-store-8080-HASH
      • The store-east-1 health check: gkemcg1-store-store-east-1-8080-HASH
      • The store-west-1 health check: gkemcg1-store-store-west-1-8080-HASH
    • 1 routing rule in the URLmap:
      • The store.example.com routing rule:
      • 1 Host: store.example.com
      • Multiple matchRules to route to the new backend services

The following diagram shows the resources you've deployed across both clusters. Because gke-west-1 is the Gateway config cluster, it is the cluster in which our Gateway, HTTPRoutes, and ServiceImports are watched by the Gateway controller. Each cluster has a store ServiceImport and another ServiceImport specific to that cluster. Both point at the same Pods. This lets the HTTPRoute to specify exactly where traffic should go - to the store Pods on a specific cluster or to the store Pods across all clusters.

This is the Gateway and Multi-cluster Service resource model across both clusters

Note that this is a logical resource model, not a depiction of the traffic flow. The traffic path goes directly from the load balancer to backend Pods and has no direct relation to whichever cluster is the config cluster.

Validating deployment

You can now issue requests to our multi-cluster Gateway and distribute traffic across both GKE clusters.

  1. Validate that the Gateway and HTTPRoute have been deployed successfully by inspecting the Gateway status and events.

    kubectl describe gateways.gateway.networking.k8s.io external-http --context gke-west-1 --namespace store

    Your output should look similar to the following:

    Name:         external-http
Namespace:    store
Labels:       <none>
Annotations:  networking.gke.io/addresses: /projects/PROJECT_NUMBER/global/addresses/gkemcg1-store-external-http-laup24msshu4
              networking.gke.io/backend-services:
                /projects/PROJECT_NUMBER/global/backendServices/gkemcg1-store-gw-serve404-80-n65xmts4xvw2, /projects/PROJECT_NUMBER/global/backendServices/gke...
              networking.gke.io/firewalls: /projects/PROJECT_NUMBER/global/firewalls/gkemcg1-l7-default-global
              networking.gke.io/forwarding-rules: /projects/PROJECT_NUMBER/global/forwardingRules/gkemcg1-store-external-http-a5et3e3itxsv
              networking.gke.io/health-checks:
                /projects/PROJECT_NUMBER/global/healthChecks/gkemcg1-store-gw-serve404-80-n65xmts4xvw2, /projects/PROJECT_NUMBER/global/healthChecks/gkemcg1-s...
              networking.gke.io/last-reconcile-time: 2023-10-12T17:54:24Z
              networking.gke.io/ssl-certificates:
              networking.gke.io/target-http-proxies: /projects/PROJECT_NUMBER/global/targetHttpProxies/gkemcg1-store-external-http-94oqhkftu5yz
              networking.gke.io/target-https-proxies:
              networking.gke.io/url-maps: /projects/PROJECT_NUMBER/global/urlMaps/gkemcg1-store-external-http-94oqhkftu5yz
API Version:  gateway.networking.k8s.io/v1
Kind:         Gateway
Metadata:
  Creation Timestamp:  2023-10-12T06:59:32Z
  Finalizers:
    gateway.finalizer.networking.gke.io
  Generation:        1
  Resource Version:  467057
  UID:               1dcb188e-2917-404f-9945-5f3c2e907b4c
Spec:
  Gateway Class Name:  gke-l7-global-external-managed-mc
  Listeners:
    Allowed Routes:
      Kinds:
        Group:  gateway.networking.k8s.io
        Kind:   HTTPRoute
      Namespaces:
        From:  Same
    Name:      http
    Port:      80
    Protocol:  HTTP
Status:
  Addresses:
    Type:   IPAddress
    Value:  34.36.127.249
  Conditions:
    Last Transition Time:  2023-10-12T07:00:41Z
    Message:               The OSS Gateway API has deprecated this condition, do not depend on it.
    Observed Generation:   1
    Reason:                Scheduled
    Status:                True
    Type:                  Scheduled
    Last Transition Time:  2023-10-12T07:00:41Z
    Message:
    Observed Generation:   1
    Reason:                Accepted
    Status:                True
    Type:                  Accepted
    Last Transition Time:  2023-10-12T07:00:41Z
    Message:
    Observed Generation:   1
    Reason:                Programmed
    Status:                True
    Type:                  Programmed
    Last Transition Time:  2023-10-12T07:00:41Z
    Message:               The OSS Gateway API has altered the "Ready" condition semantics and reservedit for future use.  GKE Gateway will stop emitting it in a future update, use "Programmed" instead.
    Observed Generation:   1
    Reason:                Ready
    Status:                True
    Type:                  Ready
  Listeners:
    Attached Routes:  1
    Conditions:
      Last Transition Time:  2023-10-12T07:00:41Z
      Message:
      Observed Generation:   1
      Reason:                Programmed
      Status:                True
      Type:                  Programmed
      Last Transition Time:  2023-10-12T07:00:41Z
      Message:               The OSS Gateway API has altered the "Ready" condition semantics and reservedit for future use.  GKE Gateway will stop emitting it in a future update, use "Programmed" instead.
      Observed Generation:   1
      Reason:                Ready
      Status:                True
      Type:                  Ready
    Name:                    http
    Supported Kinds:
      Group:  gateway.networking.k8s.io
      Kind:   HTTPRoute
Events:
  Type    Reason  Age                    From                   Message
  ----    ------  ----                   ----                   -------
  Normal  UPDATE  35m (x4 over 10h)      mc-gateway-controller  store/external-http
  Normal  SYNC    4m22s (x216 over 10h)  mc-gateway-controller  SYNC on store/external-http was a success

  2. Once the Gateway has deployed successfully retrieve the external IP address from external-http Gateway.

    kubectl get gateways.gateway.networking.k8s.io external-http -o=jsonpath="{.status.addresses[0].value}" --context gke-west-1 --namespace store

    Replace VIP in the following steps with the IP address you receive as output.

  3. Send traffic to the root path of the domain. This load balances traffic to the store ServiceImport which is across cluster gke-west-1 and gke-east-1. The load balancer sends your traffic to the closest region to you and you might not see responses from the other region.

    curl -H "host: store.example.com" http://VIP

    The output confirms that the request was served by Pod from the gke-east-1 cluster:

    {
  "cluster_name": "gke-east-1",
  "zone": "us-east1-b",
  "host_header": "store.example.com",
  "node_name": "gke-gke-east-1-default-pool-7aa30992-t2lp.c.agmsb-k8s.internal",
  "pod_name": "store-5f5b954888-dg22z",
  "pod_name_emoji": "⏭",
  "project_id": "agmsb-k8s",
  "timestamp": "2021-06-01T17:32:51"
}

  4. Next send traffic to the /west path. This routes traffic to the store-west-1 ServiceImport which only has Pods running on the gke-west-1 cluster. A cluster-specific ServiceImport, like store-west-1, enables an application owner to explicitly send traffic to a specific cluster, rather than letting the load balancer make the decision.

    curl -H "host: store.example.com" http://VIP/west

    The output confirms that the request was served by Pod from the gke-west-1 cluster:

    {
  "cluster_name": "gke-west-1",
  "zone": "us-west1-a",
  "host_header": "store.example.com",
  "node_name": "gke-gke-west-1-default-pool-65059399-2f41.c.agmsb-k8s.internal",
  "pod_name": "store-5f5b954888-d25m5",
  "pod_name_emoji": "🍾",
  "project_id": "agmsb-k8s",
  "timestamp": "2021-06-01T17:39:15",
}

  5. Finally, send traffic to the /east path.

    curl -H "host: store.example.com" http://VIP/east

    The output confirms that the request was served by Pod from the gke-east-1 cluster:

    {
  "cluster_name": "gke-east-1",
  "zone": "us-east1-b",
  "host_header": "store.example.com",
  "node_name": "gke-gke-east-1-default-pool-7aa30992-7j7z.c.agmsb-k8s.internal",
  "pod_name": "store-5f5b954888-hz6mw",
  "pod_name_emoji": "🧜🏾",
  "project_id": "agmsb-k8s",
  "timestamp": "2021-06-01T17:40:48"
}

Clean up

After completing the exercises on this document, follow these steps to remove resources and prevent unwanted charges incurring on your account:

  1. Delete the clusters.

  2. Unregister the clusters from the fleet if they don't need to be registered for another purpose.

  3. Disable the multiclusterservicediscovery feature:

    gcloud container fleet multi-cluster-services disable

  4. Disable Multi Cluster Ingress:

    gcloud container fleet ingress disable

  5. Disable the APIs:

    gcloud services disable \
    multiclusterservicediscovery.googleapis.com \
    multiclusteringress.googleapis.com \
    trafficdirector.googleapis.com \
    --project=PROJECT_ID

Troubleshooting

No healthy upstream

Symptom:

The following issue might occur when you create a Gateway but cannot access the backend services (503 response code):

no healthy upstream

Reason:

This error message indicates that the health check prober cannot find healthy backend services. It is possible that your backend services are healthy but you might need to customize the health checks.

Workaround:

To resolve this issue, customize your health check based on your application's requirements (for example, /health) using a HealthCheckPolicy.

What's next
