Trace an agent

This page shows you how to enable Cloud Trace on your agent and view traces to analyze query response times and executed operations.

A trace is a timeline of requests as your agent responds to each query. For example, the following Gantt chart shows a sample trace from a LangchainAgent:



The first row in the Gantt chart is for the trace. A trace is composed of individual spans, which represent a single unit of work, like a function call or an interaction with an LLM, with the first span representing the overall request. Each span provides details about a specific operation, such as the operation's name, start and end times, and any relevant attributes, within the request. For example, the following JSON shows a single span that represents a call to a large language model (LLM):

  {
    "name": "llm",
    "context": {
        "trace_id": "ed7b336d-e71a-46f0-a334-5f2e87cb6cfc",
        "span_id": "ad67332a-38bd-428e-9f62-538ba2fa90d4"
    },
    "span_kind": "LLM",
    "parent_id": "f89ebb7c-10f6-4bf8-8a74-57324d2556ef",
    "start_time": "2023-09-07T12:54:47.597121-06:00",
    "end_time": "2023-09-07T12:54:49.321811-06:00",
    "status_code": "OK",
    "status_message": "",
    "attributes": {
        "llm.input_messages": [
            {
                "message.role": "system",
                "message.content": "You are an expert Q&A system that is trusted around the world.\nAlways answer the query using the provided context information, and not prior knowledge.\nSome rules to follow:\n1. Never directly reference the given context in your answer.\n2. Avoid statements like 'Based on the context, ...' or 'The context information ...' or anything along those lines."
            },
            {
                "message.role": "user",
                "message.content": "Hello?"
            }
        ],
        "output.value": "assistant: Yes I am here",
        "output.mime_type": "text/plain"
    },
    "events": [],
  }

Note: The format of the trace(s) and span(s) depends on the instrumentation option you go with. The example span is experimental and subject to change so you shouldn't rely on the format to be stable for now. For details, see the Semantic Conventions for Generative AI systems being developed in OpenTelemetry.

For details, see the Cloud Trace documentation on Traces and spans and Trace context.

Write traces for an agent

To write traces for an agent:

ADK

To enable OpenTelemetry for AdkApp, set the following environment variables when you deploy the agent to Vertex AI Agent Engine Runtime:

env_vars = {
  "GOOGLE_CLOUD_AGENT_ENGINE_ENABLE_TELEMETRY": "true",
  "OTEL_INSTRUMENTATION_GENAI_CAPTURE_MESSAGE_CONTENT": "true",
}

Note the following:

• GOOGLE_CLOUD_AGENT_ENGINE_ENABLE_TELEMETRY enables the agent traces and logs, but doesn't include prompts and response data.

• OTEL_INSTRUMENTATION_GENAI_CAPTURE_MESSAGE_CONTENT enables the logging of input prompts and output responses.

• To use trace ingestion, you need to enable the Telemetry API. For more information, see Telemetry (OTLP) API overview

• To use log ingestion, you need to enable the Logging API For more information, see Cloud Logging API overview.

Note: If you were previously setting the enable_tracing flag, we recommend you use the environment variables instead. For example, set GOOGLE_CLOUD_AGENT_ENGINE_ENABLE_TELEMETRY=true instead of enable_tracing=true, and set GOOGLE_CLOUD_AGENT_ENGINE_ENABLE_TELEMETRY=false instead of enable_tracing=false.

LangchainAgent

To enable tracing for LangchainAgent, specify enable_tracing=True when you develop a LangChain agent. For example:

from vertexai.agent_engines import LangchainAgent

agent = LangchainAgent(
    model=model,                # Required.
    tools=[get_exchange_rate],  # Optional.
    enable_tracing=True,        # [New] Optional.
)

LanggraphAgent

To enable tracing for LanggraphAgent, specify enable_tracing=True when you develop a LangGraph agent. For example:

from vertexai.agent_engines import LanggraphAgent

agent = LanggraphAgent(
    model=model,                # Required.
    tools=[get_exchange_rate],  # Optional.
    enable_tracing=True,        # [New] Optional.
)

LlamaIndex

Preview

This feature is subject to the "Pre-GA Offerings Terms" in the General Service Terms section of the Service Specific Terms. Pre-GA features are available "as is" and might have limited support. For more information, see the launch stage descriptions.

To enable tracing for LlamaIndexQueryPipelineAgent, specify enable_tracing=True when you develop a LlamaIndex agent. For example:

from vertexai.preview import reasoning_engines

  def runnable_with_tools_builder(model, runnable_kwargs=None, **kwargs):
      from llama_index.core.query_pipeline import QueryPipeline
      from llama_index.core.tools import FunctionTool
      from llama_index.core.agent import ReActAgent

      llama_index_tools = []
      for tool in runnable_kwargs.get("tools"):
          llama_index_tools.append(FunctionTool.from_defaults(tool))
      agent = ReActAgent.from_tools(llama_index_tools, llm=model, verbose=True)
      return QueryPipeline(modules = {"agent": agent})

  agent = reasoning_engines.LlamaIndexQueryPipelineAgent(
      model="gemini-2.0-flash",
      runnable_kwargs={"tools": [get_exchange_rate]},
      runnable_builder=runnable_with_tools_builder,
      enable_tracing=True,        # Optional
  )

Custom

To enable tracing for custom agents, visit Tracing using OpenTelemetry for details.

This exports traces to Cloud Trace under the project in Set up your Google Cloud project.

View traces for an agent

For deployed agents, you can use the Google Cloud console to view traces for your agent:

1. In the Google Cloud console, go to the Vertex AI Agent Engine page.


   Go to Agent Engine

   Agent Engine instances that are part of the selected project appear in the list. You can use the Filter field to filter the list by your specified column.

2. Click the name of your Agent Engine instance.

3. Click the Traces tab.

4. You can select Session view or Span view.

   Click a session or span to inspect trace details, including a directed acyclic graph (DAG) of its spans, inputs and outputs, and metadata attributes.

Quotas and limits

Some attribute values might get truncated when they reach quota limits. For more information, see Cloud Trace Quota.

Pricing

Cloud Trace has a free tier. For more information, see Cloud Trace Pricing.
