販売実績に関する分析情報

このソリューション サンプルでは、SAP ERP または SAP BDC をソースとするデータを使用して、販売パフォーマンスの健全性に関する分析情報を迅速に取得する方法の例を示します。

これを使用すると、次のことができます。

• プロダクト、地域、販売組織ごとに収益を最適化する。
• 流通チャネルと部門全体のパフォーマンスをトラッキングする。
• AI を使用して、収益とコストに影響するフルフィルメントのボトルネックやオンタイム デリバリーの傾向を明らかにする。

リファレンス アーキテクチャ

ハイレベルのリファレンス アーキテクチャは、このユースケースにフィードするために必要なソース固有のデータ プロダクトの概要を示しています。

図 1 。Cortex Framework の販売実績に関する分析情報ソリューション サンプルのリファレンス アーキテクチャ。

必要なデータ プロダクト

SAP ERP をソースとするデータに基づいて構築する場合は、次の Cortex Framework データ プロダクト が必要です。

• 顧客
• 販売ドキュメント
• 販売組織
• 材質

また、コード スニペットに示すように、 KNVV などの他の SAP ERP ベーステーブルをシームレスに組み合わせて、分析情報を強化することもできます。

SAP BDC をソースとするデータに基づいて構築する場合は、次の BDC データ プロダクトが必要です。

• 顧客
• 販売注文
• 販売組織構造
• 会社
• プロダクト

コード スニペット

次のコード スニペットは、Cortex Framework をソースとする SAP ERP データ プロダクトまたは SAP BDC データ プロダクトの統合に基づいて、販売実績に関するパフォーマンス分析情報用の BigQuery データモデルを構築する方法の例を示しています。

WITH date_dimension as (

SELECT
  dt as date,
  CAST(FORMAT_DATE('%Y%m%d', dt) AS INT64) as date_int,
  FORMAT_DATE('%Y%m%d', dt) as date_str,
  FORMAT_DATE('%Y-%m-%d', dt) as date_str2,
  EXTRACT(YEAR FROM dt) as cal_year,
  IF(EXTRACT(QUARTER FROM dt) IN (1, 2), 1, 2) as cal_semester,
  EXTRACT(QUARTER FROM dt) as cal_quarter,
  EXTRACT(MONTH FROM dt) as cal_month,
  EXTRACT(WEEK FROM dt) as cal_week,
  CAST(EXTRACT(YEAR FROM dt) AS STRING) as cal_year_str,
  IF(EXTRACT(QUARTER FROM dt) IN (1, 2), '01', '02') as cal_semester_str,
  IF(EXTRACT(QUARTER FROM dt) IN (1, 2), 'S1', 'S2') as cal_semester_str2,
  '0' || EXTRACT(QUARTER FROM dt) as cal_quarter_str,
  'Q' || EXTRACT(QUARTER FROM dt) as cal_quarter_str2,
  FORMAT_DATE('%B', dt) as cal_month_long_str,
  FORMAT_DATE('%b', dt) as cal_month_short_str,
  '0' || (EXTRACT(WEEK FROM dt)) as cal_week_str,
  FORMAT_DATE('%A', dt) as day_name_long,
  FORMAT_DATE('%a', dt) as day_name_short,
  EXTRACT(DAYOFWEEK FROM dt) as day_of_week,
  EXTRACT(DAY FROM dt) as day_of_month,
  DATE_DIFF(dt, DATE_TRUNC(dt, QUARTER), DAY) + 1 as day_of_quarter,
  IF(
    EXTRACT(QUARTER FROM dt) IN (1, 2),
    EXTRACT(DAYOFYEAR FROM dt),
    IF(
      EXTRACT(QUARTER FROM dt) = 3,
      EXTRACT(DAYOFYEAR FROM dt) - EXTRACT(DAYOFYEAR FROM (DATE_TRUNC(dt, QUARTER) - 1)),
      EXTRACT(DAYOFYEAR FROM dt) - EXTRACT(DAYOFYEAR FROM (DATE_TRUNC(DATE_SUB(dt, INTERVAL 3 MONTH), QUARTER)))
    )
  ) as day_of_semester,
  EXTRACT(DAYOFYEAR FROM dt) as day_of_year,
  IF(
    EXTRACT(QUARTER FROM dt) IN (1, 2),
    EXTRACT(YEAR FROM dt) || 'S1',
    EXTRACT(YEAR FROM dt) || 'S2'
  ) as year_semester,
  EXTRACT(YEAR FROM dt) || 'Q' || EXTRACT(QUARTER FROM dt) as year_quarter,
  CAST(FORMAT_DATE('%Y%m', dt) AS STRING) as year_month,
  EXTRACT(YEAR FROM dt) || ' ' || FORMAT_DATE('%b', dt) as year_month2,
  FORMAT_DATE('%Y%U', dt) as year_week,
  (DATE_TRUNC(dt, YEAR) = dt) as is_first_day_of_year,
  (LAST_DAY(dt, YEAR) = dt) as is_last_day_of_year,
  (EXTRACT(MONTH FROM dt) IN (1, 7) AND EXTRACT(DAY FROM dt) = 1) as is_first_day_of_semester,
  ((EXTRACT(MONTH FROM dt) IN (6) AND EXTRACT(DAY FROM dt) IN (30))
    OR (EXTRACT(MONTH FROM dt) IN (12) AND EXTRACT(DAY FROM dt) IN (31))) as is_last_day_of_semester,
  (DATE_TRUNC(dt, QUARTER) = dt) as is_first_day_of_quarter,
  (LAST_DAY(dt, QUARTER) = dt) as is_last_day_of_quarter,
  (DATE_TRUNC(dt, MONTH) = dt) as is_first_day_of_month,
  (LAST_DAY(dt, MONTH) = dt) as is_last_day_of_month,
  (DATE_TRUNC(dt, WEEK) = dt) as is_first_day_of_week,
  (LAST_DAY(dt, WEEK) = dt) as is_last_day_of_week,
  ((MOD(EXTRACT(YEAR FROM dt), 4) = 0 AND MOD(EXTRACT(YEAR FROM dt), 100) != 0)
    OR MOD(EXTRACT(YEAR FROM dt), 400) = 0) as is_leap_year,
  (FORMAT_DATE('%A', dt) NOT IN ('Saturday', 'Sunday')) as is_week_day,
  (FORMAT_DATE('%A', dt) IN ('Saturday', 'Sunday')) as is_week_end,
  (DATE_TRUNC(dt, WEEK)) as week_start_date,
  (LAST_DAY(dt, WEEK)) as week_end_date,
  (DATE_TRUNC(dt, MONTH)) as month_start_date,
  (LAST_DAY(dt, MONTH)) as month_end_date,
  (EXTRACT(WEEK FROM LAST_DAY(dt, ISOYEAR)) = 53) as has_53_weeks
FROM UNNEST(GENERATE_DATE_ARRAY(
  DATE_SUB(
    DATE_TRUNC(CURRENT_DATE(), YEAR), INTERVAL 20 YEAR),
  LAST_DAY(DATE_ADD(CURRENT_DATE(), INTERVAL 20 YEAR)),
  INTERVAL 1 DAY)
) as dt

),
delivered_qty AS (
  SELECT
    client_mandt,
    internal_reference_document_number_vgbel AS sales_document_id,
    internal_reference_document_item_vgpos AS item_id,
    SUM(actual_quantity_delivered_in_sales_units_lfimg) AS total_delivered_qty
  FROM <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.delivery_document_items
  GROUP BY client_mandt, internal_reference_document_number_vgbel, internal_reference_document_item_vgpos
)
SELECT
  header.document_number_vbeln AS sales_document_id,
  item.item_number_posnr AS item_id,
  header.sales_organization_vkorg AS sales_organization_id,
  salesorg.name_vtext AS sales_organization_name,
  header.division_spart AS division_id,
  division.name_vtext AS division_name,
  header.sold_to_party_kunnr AS customer_id,
  customer.name1_name1 AS customer_name,
  item.material_number_matnr AS product_id,
  product.material_text_maktx AS product_name,
  item.net_value_of_the_sales_document_item_in_document_currency_netwr AS net_value,
  header.document_currency_waerk AS document_currency,
  header.requested_delivery_date_vdatu AS requested_delivery_date,
  header.delivery_block_lifsk AS delivery_block_reason,

  -- Using vbap.gbsta for overall status in S4
  foundation_item.gbsta AS overall_status,

  -- Deriving delivery status based on delivered quantity
  CASE
    WHEN delivered_qty.total_delivered_qty IS NULL OR delivered_qty.total_delivered_qty = 0 THEN 'A'
    WHEN delivered_qty.total_delivered_qty < item.cumulative_order_quantity_kwmeng THEN 'B'
    ELSE 'C'
  END AS delivery_status,

  salesarea.bzirk AS sales_region,

  -- Date Dimensions for Document Date
  dimensional_document_date.cal_year AS year_of_sales_document,
  dimensional_document_date.cal_month AS month_of_sales_document,
  dimensional_document_date.cal_quarter AS quarter_of_sales_document,

  -- Date Dimensions for Requested Delivery Date
  dimensional_delivery_date.cal_year AS year_of_requested_delivery,
  dimensional_delivery_date.cal_month AS month_of_requested_delivery,
  dimensional_delivery_date.cal_quarter AS quarter_of_requested_delivery,

  -- Calculated fields
  CASE
    WHEN CURRENT_DATE() > header.requested_delivery_date_vdatu
      AND (delivered_qty.total_delivered_qty IS NULL
      OR delivered_qty.total_delivered_qty < item.cumulative_order_quantity_kwmeng)
    THEN TRUE
    ELSE FALSE
  END AS is_delivery_overdue

FROM <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.sales_document_headers AS header
JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.sales_document_items AS item
  ON header.client_mandt = item.client_mandt
  AND header.document_number_vbeln = item.document_number_vbeln

-- Joins with Master Data Products for Text
LEFT JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.customers_md AS customer
  ON header.client_mandt = customer.client_mandt
  AND header.sold_to_party_kunnr = customer.customer_number_kunnr

LEFT JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.materials_md AS product
  ON item.client_mandt = product.client_mandt
  AND item.material_number_matnr = product.material_number_matnr

LEFT JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.sales_organizations_md AS salesorg
  ON header.client_mandt = salesorg.client_mandt
  AND header.sales_organization_vkorg = salesorg.sales_organization_vkorg

LEFT JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_PRODUCTS_DATASET>.divisions_md AS division
  ON header.client_mandt = division.client_mandt
  AND header.division_spart = division.division_spart

-- Join with KNVV for Sales Org Region
LEFT JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_FOUNDATION_DATASET>.knvv AS salesarea
  ON header.client_mandt = salesarea.mandt
  AND header.sold_to_party_kunnr = salesarea.kunnr
  AND header.sales_organization_vkorg = salesarea.vkorg
  AND header.distribution_channel_vtweg = salesarea.vtweg
  AND header.division_spart = salesarea.spart

-- Join with vbap directly to get gbsta (Overall Status)
LEFT JOIN <YOUR_PROJECT_ID>.<YOUR_CORTEX_DATA_FOUNDATION_DATASET>.vbap AS foundation_item
  ON item.client_mandt = foundation_item.mandt
  AND item.document_number_vbeln = foundation_item.vbeln
  AND item.item_number_posnr = foundation_item.posnr

-- Join with delivered_qty CTE
LEFT JOIN delivered_qty AS delivered_qty
  ON item.client_mandt = delivered_qty.client_mandt
  AND item.document_number_vbeln = delivered_qty.sales_document_id
  AND item.item_number_posnr = delivered_qty.item_id

-- Joins for Date Dimensions
LEFT JOIN date_dimension AS dimensional_document_date
  ON header.document_date_audat = dimensional_document_date.date
LEFT JOIN date_dimension AS dimensional_delivery_date
  ON header.requested_delivery_date_vdatu = dimensional_delivery_date.date

AI エージェントを有効にする

BigQuery で販売実績に関する分析情報データモデルを作成したら、 カスタムデータ エージェントを構築できます。これにより、複雑な SQL を使用しなくても、自然言語を使用して販売の傾向とパフォーマンス指標を直接クエリできます。
