AlloyDB Omni shared responsibility

Select a documentation version:

This page describes what you, as an AlloyDB Omni customer, are responsible for, and what Google is responsible for.

As an AlloyDB Omni customer, you are responsible for configuring and operating AlloyDB Omni to make sure that your workloads get the most value from the service.

Layer Google's responsibility Customer responsibility
Hardware and host Physical infrastructure Provide minimum and recommended requirements where applicable Provision physical servers, VMs, or edge devices like power, cooling, and hardware.
Host operating system (OS) Provide minimum and recommended requirements where applicable Manage the Linux kernel, apply OS security patches, and harden the host nodes.
Kubernetes Cluster management Provide minimum and recommended requirements where applicable Manage the cluster on a daily basis—including upgrades—following industry-standard best practices.
Storage (CSI/PV) Provide minimum and recommended requirements where applicable Provision the storage class and manage the underlying appliances.
Networking (CNI) Provide minimum and recommended requirements where applicable Provision and manage the network layer—for example, pod networking, ingress controllers, load balancers, and firewall rules between nodes.
Role-based access control (RBAC) Provide the service accounts, roles, and role bindings required for the AlloyDB Omni Kubernetes operator. Apply these role-based access control (RBAC) rules to the cluster and make sure that they align with internal security policies. To access AlloyDB Omni resources, create additional RBAC roles and role bindings.
Secret management Read standard Kubernetes Secrets to provision resources, such as the initial postgres user. Create, secure, and rotate Kubernetes Secrets in the cluster.
Certificate management Rely on standard Kubernetes Secrets and cert-manager for certificate integration. Install, configure, and manage the lifecycle of cert-manager.
Operator software Development and release Develop the AlloyDB Omni operator logic and CRDs and publish container images, Helm charts, and OLM bundles. None. You can use artifacts stored in Artifact Registry for your deployments.
Installation and lifecycle Provide documentation and upgrade artifacts.
  • Verify the compatibility table before you install or upgrade AlloyDB Omni operator.
  • Follow instructions to install or upgrade AlloyDB Omni components.
Database engine Database binary Provide the AlloyDB Omni container images with proprietary optimizations like the columnar engine and AI acceleration. None.
Patching Release security patches and minor and major version updates for the engine. Provide upgrade instructions. Schedule upgrades as soon as possible, depending on the criticality of each release.
User management
  • Provision the initial AlloyDB Omni operator operator-related users.
  • Provision the user-facing postgres superuser using a user-provided password from a Kubernetes Secret.
  • Provide instructions to integrate with Microsoft Active Directory.
  • Provide the password for the initial superuser using a Kubernetes Secret.
  • Create and manage all other roles and users.
Data management Backups Provide the `BackupPlan` and `Backup` CRDs and logic to manage backups, which are managed using pgBackrest with S3-compatible integration. Configure backup schedules and retention, and provision the local, S3 or Cloud Storage target storage bucket.
High availability (HA) Provide the auto-failover logic and healing mechanisms. Provision sufficient nodes and zones to provide a standby target to support failover.
Encryption (at rest) Provides support for Transparent Data Encryption (TDE). Manage storage layer encryption to make sure that it meets your requirements.
Encryption (in transit) Provide mTLS for internal operator components and to configure server-side TLS for user-to-database connections. Connect to the database using secure TLS clients and manage the underlying certificate infrastructure.
Observability Metrics Expose internal database metrics using a Prometheus-compatible endpoint. Deploy and manage the scraper using Prometheus, Open Telemetry, or other compatible solutions and their storage stack. Monitor the overall health of the system.
Logging Write PostgreSQL and audit logs to files on disk in the container, and rotate them. Deploy log collectors—for example, Fluentd and Fluent Bit—to ship logs to a storage backend (like Splunk or ELK). Make sure that the log collectors are extracted to preserve logs for a recommended minimum of one month.
Visualization Provide sample metrics and log dashboards to monitor standard workloads. Deploy and monitor the health of the visualization tool, like Grafana. Create dashboards and incorporate them in your daily operational tasks.
Alerting None Manage the alerting pipeline— for example, PagerDuty integration.
Support Troubleshooting Provide support for software bugs and engine errors. To obtain this support, you need a license subscription. Provide initial support through documentation and knowledge base. Debug infrastructure-related issues.
