在直播中插入广告

本页面介绍了如何使用 Video Stitcher API 和 curl、PowerShell 或客户端库将广告插播到直播中。

准备工作

在调用 Video Stitcher API 之前，请完成以下步骤：

登录您的 Google Cloud 账号。如果您是 Google Cloud新手，请创建一个账号来评估我们的产品在实际场景中的表现。新客户还可获享 $300 赠金，用于运行、测试和部署工作负载。

安装 Google Cloud CLI。

如果您使用的是外部身份提供方 (IdP)，则必须先使用联合身份登录 gcloud CLI。

如需初始化 gcloud CLI，请运行以下命令：

gcloud init

创建或选择 Google Cloud 项目。

选择或创建项目所需的角色

选择项目：选择项目不需要特定的 IAM 角色，您可以选择已获授角色的任何项目。
创建项目：如需创建项目，您需要拥有 Project Creator 角色 (roles/resourcemanager.projectCreator)，该角色包含 resourcemanager.projects.create 权限。了解如何授予角色。

创建 Google Cloud 项目：
```
gcloud projects create PROJECT_ID
```
将 PROJECT_ID 替换为您要创建的 Google Cloud 项目的名称。
选择您创建的 Google Cloud 项目：
```
gcloud config set project PROJECT_ID
```
将 PROJECT_ID 替换为您的 Google Cloud 项目名称。

验证是否已为您的 Google Cloud 项目启用结算功能。

启用 Video Stitcher API：

启用 API 所需的角色

如需启用 API，您需要拥有 Service Usage Admin IAM 角色 (roles/serviceusage.serviceUsageAdmin)，该角色包含 serviceusage.services.enable 权限。了解如何授予角色。

gcloud services enable videostitcher.googleapis.com

如果您使用的是本地 shell，请为您的用户账号创建本地身份验证凭证：

gcloud auth application-default login

如果您使用的是 Cloud Shell，则无需执行此操作。

如果系统返回身份验证错误，并且您使用的是外部身份提供方 (IdP)，请确认您已使用联合身份登录 gcloud CLI。

向您的用户账号授予角色。对以下每个 IAM 角色运行以下命令一次： roles/videostitcher.admin

gcloud projects add-iam-policy-binding PROJECT_ID --member="user:USER_IDENTIFIER" --role=ROLE

替换以下内容：

PROJECT_ID：您的项目 ID。
USER_IDENTIFIER：您的用户账号的标识符。例如，myemail@example.com。
ROLE：您授予用户账号的 IAM 角色。

安装 Google Cloud CLI。

如果您使用的是外部身份提供方 (IdP)，则必须先使用联合身份登录 gcloud CLI。

如需初始化 gcloud CLI，请运行以下命令：

gcloud init

创建或选择 Google Cloud 项目。

选择或创建项目所需的角色

选择项目：选择项目不需要特定的 IAM 角色，您可以选择已获授角色的任何项目。
创建项目：如需创建项目，您需要拥有 Project Creator 角色 (roles/resourcemanager.projectCreator)，该角色包含 resourcemanager.projects.create 权限。了解如何授予角色。

创建 Google Cloud 项目：
```
gcloud projects create PROJECT_ID
```
将 PROJECT_ID 替换为您要创建的 Google Cloud 项目的名称。
选择您创建的 Google Cloud 项目：
```
gcloud config set project PROJECT_ID
```
将 PROJECT_ID 替换为您的 Google Cloud 项目名称。

验证是否已为您的 Google Cloud 项目启用结算功能。

启用 Video Stitcher API：

启用 API 所需的角色

如需启用 API，您需要拥有 Service Usage Admin IAM 角色 (roles/serviceusage.serviceUsageAdmin)，该角色包含 serviceusage.services.enable 权限。了解如何授予角色。

gcloud services enable videostitcher.googleapis.com

如果您使用的是本地 shell，请为您的用户账号创建本地身份验证凭证：

gcloud auth application-default login

如果您使用的是 Cloud Shell，则无需执行此操作。

如果系统返回身份验证错误，并且您使用的是外部身份提供方 (IdP)，请确认您已使用联合身份登录 gcloud CLI。

向您的用户账号授予角色。对以下每个 IAM 角色运行以下命令一次： roles/videostitcher.admin

gcloud projects add-iam-policy-binding PROJECT_ID --member="user:USER_IDENTIFIER" --role=ROLE

替换以下内容：

PROJECT_ID：您的项目 ID。
USER_IDENTIFIER：您的用户账号的标识符。例如，myemail@example.com。
ROLE：您授予用户账号的 IAM 角色。

本快速入门需要 MPEG-DASH 或 HTTP Live Streaming (HLS) 清单文件。您可以按照Live Stream API 快速入门中的说明创建一个直播，直到播放生成的直播部分。
您也可以选择在此快速入门中使用内容分发网络 (CDN)。如果您尚未配置 CDN，请按照媒体 CDN 快速入门中的步骤操作，并进行以下修改：
1. 将 MPEG-DASH 或 HLS 清单文件和媒体片段上传到 Cloud Storage 存储桶。
2. 您不必将 Cloud Storage 存储桶设为可公开读取。
3. 您可以使用签名网址或未签名网址。

创建 CDN 密钥

Video Stitcher API 可以从内容分发网络 (CDN) 中提取视频。如果视频素材资源受网址签名保护，则必须向 Video Stitcher API 注册 CDN 密钥。

如需注册 CDN 密钥，请使用 projects.locations.cdnKeys.create 方法。

REST（媒体 CDN）

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：用于创建 CDN 密钥的位置；请使用某个受支持的区域
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
CDN_KEY_ID：CDN 密钥的用户定义标识符，将成为 CDN 密钥资源名称的最后一个组成部分。此 ID 只能包含小写字母、数字和连字符。第一个字符必须是字母，最后一个字符必须是字母或数字，并且整个 ID 的长度不得超过 63 个字符。
HOSTNAME：要与此 CDN 密钥关联的 CDN 的主机名（例如，IP 地址 [如 35.190.60.252] 或域名 [如 cdn.example.com]）
MEDIA_CDN_KEYNAME：媒体 CDN 密钥的密钥集名称
MEDIA_CDN_PRIVATE_KEY：以 base64 编码的字符串形式表示的 64 字节 Ed25519 私钥。如需了解详情，请参阅为媒体 CDN 创建私钥。

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI，或者使用了 Cloud Shell，这会使您自动登录 gcloud CLI。您可以通过运行 gcloud auth list 来检查当前的活跃账号。

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

cat > request.json << 'EOF'
{
  "hostname": "HOSTNAME",
  "mediaCdnKey": {
    "keyName": "MEDIA_CDN_KEYNAME",
    "privateKey": "MEDIA_CDN_PRIVATE_KEY"
  }
}
EOF

然后，执行以下命令以发送 REST 请求：

curl -X POST \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     -H "Content-Type: application/json; charset=utf-8" \
     -d @request.json \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys?cdnKeyId=CDN_KEY_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以通过运行 gcloud auth list 来检查当前的活跃账号。

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

@'
{
  "hostname": "HOSTNAME",
  "mediaCdnKey": {
    "keyName": "MEDIA_CDN_KEYNAME",
    "privateKey": "MEDIA_CDN_PRIVATE_KEY"
  }
}
'@  | Out-File -FilePath request.json -Encoding utf8

然后，执行以下命令以发送 REST 请求：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method POST `
    -Headers $headers `
    -ContentType: "application/json; charset=utf-8" `
    -InFile request.json `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys?cdnKeyId=CDN_KEY_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

此命令会创建一个长时间运行的操作 (LRO)，您可以查询该操作以跟踪进度。复制返回的 OPERATION_ID（即 name 字段的最后一部分），以便在下一部分中使用。

REST（Cloud CDN）

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：用于创建 CDN 密钥的位置；请使用某个受支持的区域
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
CDN_KEY_ID：CDN 密钥的用户定义标识符，将成为 CDN 密钥资源名称的最后一个组成部分。此 ID 只能包含小写字母、数字和连字符。第一个字符必须是字母，最后一个字符必须是字母或数字，并且整个 ID 的长度不得超过 63 个字符。
HOSTNAME：要与此 CDN 密钥关联的 CDN 的主机名（例如，IP 地址 [如 35.190.60.252] 或域名 [如 cdn.example.com]）
GCDN_KEYNAME：Cloud CDN 密钥的名称
GCDN_PRIVATE_KEY：Cloud CDN 密钥的 base64 编码字符串密钥

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

cat > request.json << 'EOF'
{
  "hostname": "HOSTNAME",
  "googleCdnKey": {
    "keyName": "GCDN_KEYNAME",
    "privateKey": "GCDN_PRIVATE_KEY"
  }
}
EOF

然后，执行以下命令以发送 REST 请求：

curl -X POST \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     -H "Content-Type: application/json; charset=utf-8" \
     -d @request.json \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys?cdnKeyId=CDN_KEY_ID"

PowerShell (Windows)

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

@'
{
  "hostname": "HOSTNAME",
  "googleCdnKey": {
    "keyName": "GCDN_KEYNAME",
    "privateKey": "GCDN_PRIVATE_KEY"
  }
}
'@  | Out-File -FilePath request.json -Encoding utf8

然后，执行以下命令以发送 REST 请求：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method POST `
    -Headers $headers `
    -ContentType: "application/json; charset=utf-8" `
    -InFile request.json `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys?cdnKeyId=CDN_KEY_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

REST (Akamai CDN)

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：用于创建 CDN 密钥的位置；请使用某个受支持的区域
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
CDN_KEY_ID：CDN 密钥的用户定义标识符，将成为 CDN 密钥资源名称的最后一个组成部分。此 ID 只能包含小写字母、数字和连字符。第一个字符必须是字母，最后一个字符必须是字母或数字，并且整个 ID 的长度不得超过 63 个字符。
HOSTNAME：要与此 CDN 密钥关联的 CDN 的主机名（例如，IP 地址 [如 35.190.60.252] 或域名 [如 cdn.example.com]）
AKAMAI_TOKEN_KEY：Akamai CDN 边缘配置的 base64 编码字符串令牌密钥

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

cat > request.json << 'EOF'
{
  "hostname": "HOSTNAME",
  "akamaiCdnKey": {
    "tokenKey": "AKAMAI_TOKEN_KEY"
  }
}
EOF

然后，执行以下命令以发送 REST 请求：

curl -X POST \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     -H "Content-Type: application/json; charset=utf-8" \
     -d @request.json \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys?cdnKeyId=CDN_KEY_ID"

PowerShell (Windows)

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

@'
{
  "hostname": "HOSTNAME",
  "akamaiCdnKey": {
    "tokenKey": "AKAMAI_TOKEN_KEY"
  }
}
'@  | Out-File -FilePath request.json -Encoding utf8

然后，执行以下命令以发送 REST 请求：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method POST `
    -Headers $headers `
    -ContentType: "application/json; charset=utf-8" `
    -InFile request.json `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys?cdnKeyId=CDN_KEY_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

C#

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 C# 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API C# API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Api.Gax.ResourceNames;
using Google.Cloud.Video.Stitcher.V1;
using Google.LongRunning;
using Google.Protobuf;
using System.Threading.Tasks;

public class CreateCdnKeySample
{
    public async Task<CdnKey> CreateCdnKeyAsync(
    string projectId, string location, string cdnKeyId, string hostname,
    string keyName, string privateKey, bool isMediaCdn)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        CdnKey cdnKey = new CdnKey
        {
            Hostname = hostname
        };

        if (isMediaCdn)
        {
            cdnKey.MediaCdnKey = new MediaCdnKey
            {
                KeyName = keyName,
                PrivateKey = ByteString.CopyFromUtf8(privateKey)
            };
        }
        else
        {
            cdnKey.GoogleCdnKey = new GoogleCdnKey
            {
                KeyName = keyName,
                PrivateKey = ByteString.CopyFromUtf8(privateKey)
            };
        }

        CreateCdnKeyRequest request = new CreateCdnKeyRequest
        {
            ParentAsLocationName = LocationName.FromProjectLocation(projectId, location),
            CdnKeyId = cdnKeyId,
            CdnKey = cdnKey
        };

        // Make the request.
        Operation<CdnKey, OperationMetadata> response = await client.CreateCdnKeyAsync(request);

        // Poll until the returned long-running operation is complete.
        Operation<CdnKey, OperationMetadata> completedResponse = await response.PollUntilCompletedAsync();

        // Retrieve the operation result.
        return completedResponse.Result;
    }
}

Go

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 Go 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API Go API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// createCDNKey creates a CDN key. A CDN key is used to retrieve protected media.
// If isMediaCDN is true, create a Media CDN key. If false, create a Cloud
// CDN key. To create a privateKey value for Media CDN, see
// https://cloud.google.com/video-stitcher/docs/how-to/managing-cdn-keys#create-private-key-media-cdn.
func createCDNKey(w io.Writer, projectID, keyID, privateKey string, isMediaCDN bool) error {
	// projectID := "my-project-id"
	// keyID := "my-cdn-key"
	// privateKey := "my-private-key"
	// isMediaCDN := true
	location := "us-central1"
	hostname := "cdn.example.com"
	keyName := "cdn-key"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	var req *stitcherstreampb.CreateCdnKeyRequest
	if isMediaCDN {
		req = &stitcherstreampb.CreateCdnKeyRequest{
			Parent:   fmt.Sprintf("projects/%s/locations/%s", projectID, location),
			CdnKeyId: keyID,
			CdnKey: &stitcherstreampb.CdnKey{
				CdnKeyConfig: &stitcherstreampb.CdnKey_MediaCdnKey{
					MediaCdnKey: &stitcherstreampb.MediaCdnKey{
						KeyName:    keyName,
						PrivateKey: []byte(privateKey),
					},
				},
				Hostname: hostname,
			},
		}
	} else {
		req = &stitcherstreampb.CreateCdnKeyRequest{
			Parent:   fmt.Sprintf("projects/%s/locations/%s", projectID, location),
			CdnKeyId: keyID,
			CdnKey: &stitcherstreampb.CdnKey{
				CdnKeyConfig: &stitcherstreampb.CdnKey_GoogleCdnKey{
					GoogleCdnKey: &stitcherstreampb.GoogleCdnKey{
						KeyName:    keyName,
						PrivateKey: []byte(privateKey),
					},
				},
				Hostname: hostname,
			},
		}
	}

	// Creates the CDN key.
	op, err := client.CreateCdnKey(ctx, req)
	if err != nil {
		return fmt.Errorf("client.CreateCdnKey: %w", err)
	}
	response, err := op.Wait(ctx)
	if err != nil {
		return err
	}

	fmt.Fprintf(w, "CDN key: %v", response.GetName())
	return nil
}

Java

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 Java 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API Java API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.CdnKey;
import com.google.cloud.video.stitcher.v1.CreateCdnKeyRequest;
import com.google.cloud.video.stitcher.v1.GoogleCdnKey;
import com.google.cloud.video.stitcher.v1.LocationName;
import com.google.cloud.video.stitcher.v1.MediaCdnKey;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import com.google.protobuf.ByteString;
import java.io.IOException;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class CreateCdnKey {

  private static final int TIMEOUT_IN_MINUTES = 2;

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String cdnKeyId = "my-cdn-key-id";
    String hostname = "cdn.example.com";
    String keyName = "my-key";
    // To create a privateKey value for Media CDN, see
    // https://cloud.google.com/video-stitcher/docs/how-to/managing-cdn-keys#create-private-key-media-cdn.
    String privateKey = "my-private-key"; // will be converted to a byte string
    Boolean isMediaCdn = true;

    createCdnKey(projectId, location, cdnKeyId, hostname, keyName, privateKey, isMediaCdn);
  }

  // createCdnKey creates a Media CDN key or a Cloud CDN key. A CDN key is used to retrieve
  // protected media.
  public static CdnKey createCdnKey(
      String projectId,
      String location,
      String cdnKeyId,
      String hostname,
      String keyName,
      String privateKey,
      Boolean isMediaCdn)
      throws IOException, ExecutionException, InterruptedException, TimeoutException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      CdnKey cdnKey;
      if (isMediaCdn) {
        cdnKey =
            CdnKey.newBuilder()
                .setHostname(hostname)
                .setMediaCdnKey(
                    MediaCdnKey.newBuilder()
                        .setKeyName(keyName)
                        .setPrivateKey(ByteString.copyFromUtf8(privateKey))
                        .build())
                .build();
      } else {
        cdnKey =
            CdnKey.newBuilder()
                .setHostname(hostname)
                .setGoogleCdnKey(
                    GoogleCdnKey.newBuilder()
                        .setKeyName(keyName)
                        .setPrivateKey(ByteString.copyFromUtf8(privateKey))
                        .build())
                .build();
      }

      CreateCdnKeyRequest createCdnKeyRequest =
          CreateCdnKeyRequest.newBuilder()
              .setParent(LocationName.of(projectId, location).toString())
              .setCdnKeyId(cdnKeyId)
              .setCdnKey(cdnKey)
              .build();

      CdnKey result =
          videoStitcherServiceClient
              .createCdnKeyAsync(createCdnKeyRequest)
              .get(TIMEOUT_IN_MINUTES, TimeUnit.MINUTES);
      System.out.println("Created new CDN key: " + result.getName());
      return result;
    }
  }
}

Node.js

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 Node.js 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API Node.js API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

const location = 'us-central1';
const hostname = 'cdn.example.com';
const keyName = 'cdn-key';
/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// cdnKeyId = 'my-cdn-key';
// privateKey = 'my-private-key';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function createCdnKey() {
  // Construct request
  const request = {
    parent: stitcherClient.locationPath(projectId, location),
    cdnKey: {
      hostname: hostname,
    },
    cdnKeyId: cdnKeyId,
  };

  if (isMediaCdn === 'true') {
    request.cdnKey.mediaCdnKey = {
      keyName: keyName,
      privateKey: privateKey,
    };
  } else {
    request.cdnKey.googleCdnKey = {
      keyName: keyName,
      privateKey: privateKey,
    };
  }

  const [operation] = await stitcherClient.createCdnKey(request);
  const [response] = await operation.promise();
  console.log(`CDN key: ${response.name}`);
}

createCdnKey().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 PHP 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API PHP API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\CdnKey;
use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\CreateCdnKeyRequest;
use Google\Cloud\Video\Stitcher\V1\GoogleCdnKey;
use Google\Cloud\Video\Stitcher\V1\MediaCdnKey;

/**
 * Creates a CDN key. Cloud CDN keys and Media CDN keys are supported.
 *
 * @param string  $callingProjectId   The project ID to run the API call under
 * @param string  $location           The location of the CDN key
 * @param string  $cdnKeyId           The ID of the CDN key to be created
 * @param string  $hostname           The hostname of the CDN key
 * @param string  $keyName            For a Media CDN key, this is the keyset name.
 *                                    For a Cloud CDN key, this is the public name of the
 *                                    CDN key.
 * @param string  $privateKey         For a Media CDN key, this is a 64-byte Ed25519 private
 *                                    key encoded as a base64-encoded string. See
 *                                    https://cloud.google.com/video-stitcher/docs/how-to/managing-cdn-keys#create-private-key-media-cdn
 *                                    for more information. For a Cloud CDN key,
 *                                    this is a base64-encoded string secret.
 * @param bool    $isMediaCdn         If true, create a Media CDN key. If false,
 *                                    create a Cloud CDN key.
 */
function create_cdn_key(
    string $callingProjectId,
    string $location,
    string $cdnKeyId,
    string $hostname,
    string $keyName,
    string $privateKey,
    bool $isMediaCdn
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $parent = $stitcherClient->locationName($callingProjectId, $location);
    $cdnKey = new CdnKey();
    $cdnKey->setHostname($hostname);

    if ($isMediaCdn == true) {
        $cloudCdn = new MediaCdnKey();
        $cdnKey->setMediaCdnKey($cloudCdn);
    } else {
        $cloudCdn = new GoogleCdnKey();
        $cdnKey->setGoogleCdnKey($cloudCdn);
    }
    $cloudCdn->setKeyName($keyName);
    $cloudCdn->setPrivateKey($privateKey);

    // Run CDN key creation request
    $request = (new CreateCdnKeyRequest())
        ->setParent($parent)
        ->setCdnKey($cdnKey)
        ->setCdnKeyId($cdnKeyId);
    $operationResponse = $stitcherClient->createCdnKey($request);
    $operationResponse->pollUntilComplete();
    if ($operationResponse->operationSucceeded()) {
        $result = $operationResponse->getResult();
        // Print results
        printf('CDN key: %s' . PHP_EOL, $result->getName());
    } else {
        $error = $operationResponse->getError();
        // handleError($error)
    }
}

Python

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 Python 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API Python API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video import stitcher_v1
from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)


def create_cdn_key(
    project_id: str,
    location: str,
    cdn_key_id: str,
    hostname: str,
    key_name: str,
    private_key: str,
    is_cloud_cdn: bool,
) -> stitcher_v1.types.CdnKey:
    """Creates a Cloud CDN or Media CDN key.
    Args:
        project_id: The GCP project ID.
        location: The location in which to create the CDN key.
        cdn_key_id: The user-defined CDN key ID.
        hostname: The hostname to which this CDN key applies.
        key_name: For a Media CDN key, this is the keyset name.
                  For a Cloud CDN key, this is the public name of the CDN key.
        private_key: For a Media CDN key, this is a 64-byte Ed25519 private
                     key encoded as a base64-encoded string.
                     See https://cloud.google.com/video-stitcher/docs/how-to/managing-cdn-keys#create-private-key-media-cdn
                     for more information. For a Cloud CDN key, this is a base64-encoded string secret.
        is_cloud_cdn: If true, create a Cloud CDN key. If false, create a Media CDN key.

    Returns:
        The CDN key resource.
    """

    client = VideoStitcherServiceClient()

    parent = f"projects/{project_id}/locations/{location}"

    cdn_key = stitcher_v1.types.CdnKey(
        name=cdn_key_id,
        hostname=hostname,
    )

    if is_cloud_cdn:
        cdn_key.google_cdn_key = stitcher_v1.types.GoogleCdnKey(
            key_name=key_name,
            private_key=private_key,
        )
    else:
        cdn_key.media_cdn_key = stitcher_v1.types.MediaCdnKey(
            key_name=key_name,
            private_key=private_key,
        )

    operation = client.create_cdn_key(
        parent=parent, cdn_key_id=cdn_key_id, cdn_key=cdn_key
    )
    response = operation.result()
    print(f"CDN key: {response.name}")
    return response

Ruby

在试用此示例之前，请按照《Video Stitcher API 快速入门：使用客户端库》中的 Ruby 设置说明进行操作。如需了解详情，请参阅 Video Stitcher API Ruby API 参考文档。

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Create a Media CDN or Cloud CDN key
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param cdn_key_id [String] The user-defined CDN key ID
# @param hostname [String] The hostname to which this CDN key applies
# @param key_name [String] For a Media CDN key, this is the keyset name.
#   For a Cloud CDN key, this is the public name of the CDN key.
# @param private_key [String] For a Media CDN key, this is a 64-byte Ed25519
#   private key encoded as a base64-encoded string. See
#   https://cloud.google.com/video-stitcher/docs/how-to/managing-cdn-keys#create-private-key-media-cdn
#   for more information. For a Cloud CDN key, this is a base64-encoded string
#   secret.
# @param is_media_cdn [Boolean] If true, create a Media CDN key. If false,
#  create a Cloud CDN key.
#
def create_cdn_key project_id:, location:, cdn_key_id:, hostname:, key_name:,
                   private_key:, is_media_cdn:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the parent.
  parent = client.location_path project: project_id, location: location
  # Build the path for the CDN key resource.
  cdn_key_path = client.cdn_key_path project: project_id, location: location,
                                     cdn_key: cdn_key_id

  # Set the CDN key fields.
  new_cdn_key = if is_media_cdn
                  {
                    name: cdn_key_path,
                    hostname: hostname,
                    media_cdn_key: {
                      key_name: key_name,
                      private_key: private_key
                    }
                  }
                else
                  {
                    name: cdn_key_path,
                    hostname: hostname,
                    google_cdn_key: {
                      key_name: key_name,
                      private_key: private_key
                    }
                  }
                end

  operation = client.create_cdn_key parent: parent, cdn_key: new_cdn_key,
                                    cdn_key_id: cdn_key_id

  # The returned object is of type Gapic::Operation. You can use this
  # object to check the status of an operation, cancel it, or wait
  # for results. Here is how to block until completion:
  operation.wait_until_done!

  # Print the CDN key name.
  puts "CDN key: #{operation.response.name}"
end

检查结果

如需检查 CDN 密钥是否已创建，请使用 projects.locations.operations.get 方法。如果响应包含 "done: false"，请重复执行该命令，直到响应包含 "done: true"。

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：数据的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
OPERATION_ID：操作的标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI，或者使用了 Cloud Shell，这会使您自动登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

curl -X GET \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method GET `
    -Headers $headers `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "endTime": END_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": true,
  "response": {
    "@type": "type.googleapis.com/google.cloud.video.stitcher.v1.CdnKey",
    "name": "projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID",
    "hostname": "HOSTNAME",
    "mediaCdnKey": {
      "keyName": "MEDIA_CDN_KEYNAME"
    }
  }
}

创建补位广告

当无法插入广告时，Video Stitcher API 会插入默认的补位视频。您必须向 Video Stitcher API 注册补位视频，以指明在没有广告时将使用的补位内容。补位内容视频可以是任何包含至少一个音轨的 MP4 文件。

如需创建补位内容，请使用 projects.locations.slates.create 方法。

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：要创建补位内容的位置；请使用某个受支持的区域
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
SLATE_ID：用户定义的平板标识符。此 ID 只能包含小写字母、数字和连字符。第一个字符必须是字母，最后一个字符必须是字母或数字，并且整个 ID 的长度不得超过 63 个字符。
SLATE_URL：MP4 视频的公开 URI，该视频至少包含一个音轨（示例视频）

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

cat > request.json << 'EOF'
{
  "uri": "SLATE_URL"
}
EOF

然后，执行以下命令以发送 REST 请求：

curl -X POST \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     -H "Content-Type: application/json; charset=utf-8" \
     -d @request.json \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/slates?slateId=SLATE_ID"

PowerShell (Windows)

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

@'
{
  "uri": "SLATE_URL"
}
'@  | Out-File -FilePath request.json -Encoding utf8

然后，执行以下命令以发送 REST 请求：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method POST `
    -Headers $headers `
    -ContentType: "application/json; charset=utf-8" `
    -InFile request.json `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/slates?slateId=SLATE_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Api.Gax.ResourceNames;
using Google.Cloud.Video.Stitcher.V1;
using Google.LongRunning;
using System.Threading.Tasks;

public class CreateSlateSample
{
    public async Task<Slate> CreateSlateAsync(
        string projectId, string location, string slateId, string slateUri)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        CreateSlateRequest request = new CreateSlateRequest
        {
            ParentAsLocationName = LocationName.FromProjectLocation(projectId, location),
            SlateId = slateId,
            Slate = new Slate
            {
                Uri = slateUri
            }
        };

        // Make the request.
        Operation<Slate, OperationMetadata> response = await client.CreateSlateAsync(request);

        // Poll until the returned long-running operation is complete.
        Operation<Slate, OperationMetadata> completedResponse = await response.PollUntilCompletedAsync();

        // Retrieve the operation result.
        return completedResponse.Result;
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// createSlate creates a slate. A slate is displayed when ads are not available.
func createSlate(w io.Writer, projectID, slateID, slateURI string) error {
	// projectID := "my-project-id"
	// slateID := "my-slate-id"
	// slateURI := "https://my-slate-uri/test.mp4"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	req := &stitcherstreampb.CreateSlateRequest{
		Parent:  fmt.Sprintf("projects/%s/locations/%s", projectID, location),
		SlateId: slateID,
		Slate: &stitcherstreampb.Slate{
			Uri: slateURI,
		},
	}
	// Creates the slate.
	op, err := client.CreateSlate(ctx, req)
	if err != nil {
		return fmt.Errorf("client.CreateSlate: %w", err)
	}
	response, err := op.Wait(ctx)
	if err != nil {
		return err
	}

	fmt.Fprintf(w, "Slate: %v", response.GetName())
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.CreateSlateRequest;
import com.google.cloud.video.stitcher.v1.LocationName;
import com.google.cloud.video.stitcher.v1.Slate;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class CreateSlate {

  private static final int TIMEOUT_IN_MINUTES = 2;

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String slateId = "my-slate-id";
    String slateUri =
        "https://my-slate-uri/test.mp4"; // URI of an MP4 video with at least one audio track

    createSlate(projectId, location, slateId, slateUri);
  }

  // Creates a slate. Slates are content that can be served when there are gaps in a livestream
  // ad break that cannot be filled with a dynamically served ad. For more information, see
  // https://cloud.google.com/video-stitcher/docs/how-to/managing-slates.
  public static Slate createSlate(
      String projectId, String location, String slateId, String slateUri)
      throws IOException, ExecutionException, InterruptedException, TimeoutException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      CreateSlateRequest createSlateRequest =
          CreateSlateRequest.newBuilder()
              .setParent(LocationName.of(projectId, location).toString())
              .setSlateId(slateId)
              .setSlate(Slate.newBuilder().setUri(slateUri).build())
              .build();

      Slate response =
          videoStitcherServiceClient
              .createSlateAsync(createSlateRequest)
              .get(TIMEOUT_IN_MINUTES, TimeUnit.MINUTES);
      System.out.println("Created new slate: " + response.getName());
      return response;
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// slateId = 'my-slate';
// slateUri = 'https://my-slate-uri/test.mp4';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function createSlate() {
  // Construct request
  const request = {
    parent: stitcherClient.locationPath(projectId, location),
    slate: {
      uri: slateUri,
    },
    slateId: slateId,
  };
  const [operation] = await stitcherClient.createSlate(request);
  const [response] = await operation.promise();
  console.log(`response.name: ${response.name}`);
}

createSlate().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\CreateSlateRequest;
use Google\Cloud\Video\Stitcher\V1\Slate;

/**
 * Creates a slate. A slate is displayed when ads are not available.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the slate
 * @param string $slateId              The name of the slate to be created
 * @param string $slateUri             The public URI for an MP4 video with at least one audio track
 */
function create_slate(
    string $callingProjectId,
    string $location,
    string $slateId,
    string $slateUri
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $parent = $stitcherClient->locationName($callingProjectId, $location);
    $slate = new Slate();
    $slate->setUri($slateUri);

    // Run slate creation request
    $request = (new CreateSlateRequest())
        ->setParent($parent)
        ->setSlateId($slateId)
        ->setSlate($slate);
    $operationResponse = $stitcherClient->createSlate($request);
    $operationResponse->pollUntilComplete();
    if ($operationResponse->operationSucceeded()) {
        $result = $operationResponse->getResult();
        // Print results
        printf('Slate: %s' . PHP_EOL, $result->getName());
    } else {
        $error = $operationResponse->getError();
        // handleError($error)
    }
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video import stitcher_v1
from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)


def create_slate(
    project_id: str, location: str, slate_id: str, slate_uri: str
) -> stitcher_v1.types.Slate:
    """Creates a slate.
    Args:
        project_id: The GCP project ID.
        location: The location in which to create the slate.
        slate_id: The user-defined slate ID.
        slate_uri: Uri of the video slate; must be an MP4 video with at least one audio track.

    Returns:
        The slate resource.
    """

    client = VideoStitcherServiceClient()

    parent = f"projects/{project_id}/locations/{location}"

    slate = stitcher_v1.types.Slate(
        uri=slate_uri,
    )

    operation = client.create_slate(parent=parent, slate_id=slate_id, slate=slate)
    response = operation.result()
    print(f"Slate: {response.name}")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Create a slate
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param slate_id [String] Your slate name (e.g. `my-slate`)
# @param slate_uri [String] The URI of an MP4 video with at least one audio
#   track (e.g. `https://my-slate-uri/test.mp4`)
#
def create_slate project_id:, location:, slate_id:, slate_uri:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the parent.
  parent = client.location_path project: project_id, location: location

  # Set the slate fields.
  new_slate = {
    uri: slate_uri
  }

  operation = client.create_slate parent: parent, slate_id: slate_id,
                                  slate: new_slate

  # The returned object is of type Gapic::Operation. You can use this
  # object to check the status of an operation, cancel it, or wait
  # for results. Here is how to block until completion:
  operation.wait_until_done!

  # Print the slate name.
  puts "Slate: #{operation.response.name}"
end

检查结果

如需检查补位内容是否已创建，请使用 projects.locations.operations.get 方法。如果响应包含 "done: false"，请重复执行该命令，直到响应包含 "done: true"。

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：数据的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
OPERATION_ID：操作的标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

执行以下命令：

curl -X GET \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method GET `
    -Headers $headers `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "endTime": END_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": true,
  "response": {
    "@type": "type.googleapis.com/google.cloud.video.stitcher.v1.Slate",
    "name": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
    "uri": "SLATE_URL"
  }
}

创建直播配置

在创建直播会话之前，您需要先为其创建配置。许多直播会话可以共用同一配置。

如需创建配置，请使用 projects.locations.liveConfigs.create 方法。

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：创建直播配置的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
LIVE_CONFIG_ID：用户定义的实时配置标识符。此 ID 只能包含小写字母、数字和连字符。第一个字符必须是字母，最后一个字符必须是字母或数字，并且整个 ID 的长度不得超过 63 个字符。
SOURCE_LIVESTREAM_URI：直播清单的 URI；请使用公开 URI 或您已注册 CDN 密钥的未签名 URI
```
AD_TAG_URI
```
默认广告代码的公开 URI。如果您没有，可以使用单个内嵌线性示例。
SLATE_ID：在没有拼接广告的情况下要使用的补位内容的 ID

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

cat > request.json << 'EOF'
{
  "sourceUri": "SOURCE_LIVESTREAM_URI",
  "adTagUri": "AD_TAG_URI",
  "defaultSlate": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
  "adTracking": "SERVER",
  "stitchingPolicy": "CUT_CURRENT"
}
EOF

然后，执行以下命令以发送 REST 请求：

curl -X POST \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     -H "Content-Type: application/json; charset=utf-8" \
     -d @request.json \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs?liveConfigId=LIVE_CONFIG_ID"

PowerShell (Windows)

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

@'
{
  "sourceUri": "SOURCE_LIVESTREAM_URI",
  "adTagUri": "AD_TAG_URI",
  "defaultSlate": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
  "adTracking": "SERVER",
  "stitchingPolicy": "CUT_CURRENT"
}
'@  | Out-File -FilePath request.json -Encoding utf8

然后，执行以下命令以发送 REST 请求：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method POST `
    -Headers $headers `
    -ContentType: "application/json; charset=utf-8" `
    -InFile request.json `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs?liveConfigId=LIVE_CONFIG_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID",
    "verb": "create",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

此命令会创建一个长时间运行的操作 (LRO)，您可以查询该操作以跟踪进度。如需了解详情，请参阅检查结果。

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Api.Gax.ResourceNames;
using Google.Cloud.Video.Stitcher.V1;
using Google.LongRunning;
using System.Threading.Tasks;

public class CreateLiveConfigSample
{
    public async Task<LiveConfig> CreateLiveConfigAsync(
        string projectId, string location, string liveConfigId, string sourceUri, string adTagUri, string slateId)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        CreateLiveConfigRequest request = new CreateLiveConfigRequest
        {
            ParentAsLocationName = LocationName.FromProjectLocation(projectId, location),
            LiveConfigId = liveConfigId,
            LiveConfig = new LiveConfig
            {
                SourceUri = sourceUri,
                AdTagUri = adTagUri,
                DefaultSlate = SlateName.FormatProjectLocationSlate(projectId, location, slateId),
                AdTracking = AdTracking.Server,
                StitchingPolicy = LiveConfig.Types.StitchingPolicy.CutCurrent
            }
        };

        // Make the request.
        Operation<LiveConfig, OperationMetadata> response = await client.CreateLiveConfigAsync(request);

        // Poll until the returned long-running operation is complete.
        Operation<LiveConfig, OperationMetadata> completedResponse = await response.PollUntilCompletedAsync();

        // Retrieve the operation result.
        return completedResponse.Result;
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// createLiveConfig creates a live config. Live configs are used to configure live sessions.
func createLiveConfig(w io.Writer, projectID, liveConfigID, sourceURI, slateID string) error {
	// projectID := "my-project-id"
	// liveConfigID := "my-live-config-id"

	// Uri of the media to stitch; this URI must reference either an MPEG-DASH
	// manifest (.mpd) file or an M3U playlist manifest (.m3u8) file.
	// sourceURI := "https://storage.googleapis.com/my-bucket/main.mpd"

	// See https://cloud.google.com/video-stitcher/docs/concepts for information
	// on ad tags and ad metadata. This sample uses an ad tag URL that displays
	// a Single Inline Linear ad
	// (https://developers.google.com/interactive-media-ads/docs/sdks/html5/client-side/tags).
	adTagURI := "https://pubads.g.doubleclick.net/gampad/ads?iu=/21775744923/external/single_ad_samples&sz=640x480&cust_params=sample_ct%3Dlinear&ciu_szs=300x250%2C728x90&gdfp_req=1&output=vast&unviewed_position_start=1&env=vp&impl=s&correlator="
	// slateID := "my-slate-id"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	req := &stitcherstreampb.CreateLiveConfigRequest{
		Parent:       fmt.Sprintf("projects/%s/locations/%s", projectID, location),
		LiveConfigId: liveConfigID,
		LiveConfig: &stitcherstreampb.LiveConfig{
			SourceUri:       sourceURI,
			AdTagUri:        adTagURI,
			AdTracking:      stitcherstreampb.AdTracking_SERVER,
			StitchingPolicy: stitcherstreampb.LiveConfig_CUT_CURRENT,
			DefaultSlate:    fmt.Sprintf("projects/%s/locations/%s/slates/%s", projectID, location, slateID),
		},
	}
	// Creates the live config.
	op, err := client.CreateLiveConfig(ctx, req)
	if err != nil {
		return fmt.Errorf("client.createLiveConfig: %w", err)
	}
	response, err := op.Wait(ctx)
	if err != nil {
		return err
	}

	fmt.Fprintf(w, "Live config: %v", response.GetName())
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.AdTracking;
import com.google.cloud.video.stitcher.v1.CreateLiveConfigRequest;
import com.google.cloud.video.stitcher.v1.LiveConfig;
import com.google.cloud.video.stitcher.v1.LiveConfig.StitchingPolicy;
import com.google.cloud.video.stitcher.v1.LocationName;
import com.google.cloud.video.stitcher.v1.SlateName;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class CreateLiveConfig {

  private static final int TIMEOUT_IN_MINUTES = 2;

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String liveConfigId = "my-live-config-id";
    // Uri of the live stream to stitch; this URI must reference either an MPEG-DASH
    // manifest (.mpd) file or an M3U playlist manifest (.m3u8) file.
    String sourceUri = "https://storage.googleapis.com/my-bucket/main.mpd";
    // See Single Inline Linear
    // (https://developers.google.com/interactive-media-ads/docs/sdks/html5/client-side/tags)
    String adTagUri = "https://pubads.g.doubleclick.net/gampad/ads...";
    String slateId = "my-slate-id";

    createLiveConfig(projectId, location, liveConfigId, sourceUri, adTagUri, slateId);
  }

  // Creates a live config. Live configs are used to configure live sessions.
  // For more information, see
  // https://cloud.google.com/video-stitcher/docs/how-to/managing-live-configs.
  public static LiveConfig createLiveConfig(
      String projectId,
      String location,
      String liveConfigId,
      String sourceUri,
      String adTagUri,
      String slateId)
      throws IOException, ExecutionException, InterruptedException, TimeoutException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      CreateLiveConfigRequest createLiveConfigRequest =
          CreateLiveConfigRequest.newBuilder()
              .setParent(LocationName.of(projectId, location).toString())
              .setLiveConfigId(liveConfigId)
              .setLiveConfig(
                  LiveConfig.newBuilder()
                      .setSourceUri(sourceUri)
                      .setAdTagUri(adTagUri)
                      .setDefaultSlate(SlateName.format(projectId, location, slateId))
                      .setAdTracking(AdTracking.SERVER)
                      .setStitchingPolicy(StitchingPolicy.CUT_CURRENT)
                      .build())
              .build();

      LiveConfig response =
          videoStitcherServiceClient
              .createLiveConfigAsync(createLiveConfigRequest)
              .get(TIMEOUT_IN_MINUTES, TimeUnit.MINUTES);
      System.out.println("Created new live config: " + response.getName());
      return response;
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// liveConfigId = 'my-live-config-id';
// sourceUri = 'https://storage.googleapis.com/my-bucket/main.mpd';
// See Single Inline Linear
// (https://developers.google.com/interactive-media-ads/docs/sdks/html5/client-side/tags)
// adTagUri = 'https://pubads.g.doubleclick.net/gampad/ads...';
// slateId = 'my-slate';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function createLiveConfig() {
  // Construct request
  const request = {
    parent: stitcherClient.locationPath(projectId, location),
    liveConfig: {
      sourceUri: sourceUri,
      adTagUri: adTagUri,
      adTracking: 'SERVER',
      stitchingPolicy: 'CUT_CURRENT',
      defaultSlate: stitcherClient.slatePath(projectId, location, slateId),
    },
    liveConfigId: liveConfigId,
  };
  const [operation] = await stitcherClient.createLiveConfig(request);
  const [response] = await operation.promise();
  console.log(`response.name: ${response.name}`);
}

createLiveConfig().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\AdTracking;
use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\CreateLiveConfigRequest;
use Google\Cloud\Video\Stitcher\V1\LiveConfig;

/**
 * Creates a live config. Live configs are used to configure live sessions.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the live config
 * @param string $liveConfigId         The name of the live config to be created
 * @param string $sourceUri            Uri of the media to stitch; this URI must
 *                                     reference either an MPEG-DASH manifest
 *                                     (.mpd) file or an M3U playlist manifest
 *                                     (.m3u8) file.
 * @param string $adTagUri             The Uri of the ad tag
 * @param string $slateId              The user-defined slate ID of the default
 *                                     slate to use when no slates are specified
 *                                     in an ad break's message
 */
function create_live_config(
    string $callingProjectId,
    string $location,
    string $liveConfigId,
    string $sourceUri,
    string $adTagUri,
    string $slateId
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $parent = $stitcherClient->locationName($callingProjectId, $location);
    $defaultSlate = $stitcherClient->slateName($callingProjectId, $location, $slateId);

    $liveConfig = (new LiveConfig())
        ->setSourceUri($sourceUri)
        ->setAdTagUri($adTagUri)
        ->setAdTracking(AdTracking::SERVER)
        ->setStitchingPolicy(LiveConfig\StitchingPolicy::CUT_CURRENT)
        ->setDefaultSlate($defaultSlate);

    // Run live config creation request
    $request = (new CreateLiveConfigRequest())
        ->setParent($parent)
        ->setLiveConfigId($liveConfigId)
        ->setLiveConfig($liveConfig);
    $operationResponse = $stitcherClient->createLiveConfig($request);
    $operationResponse->pollUntilComplete();
    if ($operationResponse->operationSucceeded()) {
        $result = $operationResponse->getResult();
        // Print results
        printf('Live config: %s' . PHP_EOL, $result->getName());
    } else {
        $error = $operationResponse->getError();
        // handleError($error)
    }
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video import stitcher_v1
from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)


def create_live_config(
    project_id: str,
    location: str,
    live_config_id: str,
    live_stream_uri: str,
    ad_tag_uri: str,
    slate_id: str,
) -> stitcher_v1.types.LiveConfig:
    """Creates a live config.
    Args:
        project_id: The GCP project ID.
        location: The location in which to create the live config.
        live_config_id: The user-defined live config ID.
        live_stream_uri: Uri of the livestream to stitch; this URI must reference either an MPEG-DASH
                    manifest (.mpd) file or an M3U playlist manifest (.m3u8) file.
        ad_tag_uri: Uri of the ad tag.
        slate_id: The user-defined slate ID of the default slate to use when no slates are specified in an ad break's message.

    Returns:
        The live config resource.
    """

    client = VideoStitcherServiceClient()

    parent = f"projects/{project_id}/locations/{location}"
    default_slate = f"projects/{project_id}/locations/{location}/slates/{slate_id}"

    live_config = stitcher_v1.types.LiveConfig(
        source_uri=live_stream_uri,
        ad_tag_uri=ad_tag_uri,
        ad_tracking="SERVER",
        stitching_policy="CUT_CURRENT",
        default_slate=default_slate,
    )

    operation = client.create_live_config(
        parent=parent, live_config_id=live_config_id, live_config=live_config
    )
    response = operation.result()
    print(f"Live config: {response.name}")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Create a live config
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param live_config_id [String] Your live config name (e.g. `my-live-config`)
# @param source_uri [String] Uri of the live stream to stitch
#   (e.g. `https://storage.googleapis.com/my-bucket/main.mpd`)
# @param ad_tag_uri [String] Uri of the ad tag
#   (e.g. `https://pubads.g.doubleclick.net/gampad/ads...`)
# @param slate_id [String] The default slate ID to use when no slates are
#   specified in an ad break's message (e.g. `my-slate-id`)
#
def create_live_config project_id:, location:, live_config_id:, source_uri:,
                       ad_tag_uri:, slate_id:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the parent.
  parent = client.location_path project: project_id, location: location

  # Build the resource name of the default slate.
  slate_name = client.slate_path project: project_id, location: location,
                                 slate: slate_id

  # Set the live config fields.
  new_live_config = {
    source_uri: source_uri,
    ad_tag_uri: ad_tag_uri,
    ad_tracking: Google::Cloud::Video::Stitcher::V1::AdTracking::SERVER,
    stitching_policy: Google::Cloud::Video::Stitcher::V1::LiveConfig::StitchingPolicy::CUT_CURRENT,
    default_slate: slate_name
  }

  operation = client.create_live_config parent: parent,
                                        live_config_id: live_config_id,
                                        live_config: new_live_config

  # The returned object is of type Gapic::Operation. You can use this
  # object to check the status of an operation, cancel it, or wait
  # for results. Here is how to block until completion:
  operation.wait_until_done!

  # Print the live config name.
  puts "Live config: #{operation.response.name}"
end

获取配置

如需获取配置，请使用 projects.locations.liveConfigs.get 方法。

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：实时配置的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
LIVE_CONFIG_ID：实时配置的用户定义标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

执行以下命令：

curl -X GET \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method GET `
    -Headers $headers `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID",
  "sourceUri": "SOURCE_LIVESTREAM_URI",
  "adTagUri": "AD_TAG_URI",
  "state": "READY",
  "adTracking": "SERVER",
  "defaultSlate": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
  "stitchingPolicy": "CUT_CURRENT"
}

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Cloud.Video.Stitcher.V1;

public class GetLiveConfigSample
{
    public LiveConfig GetLiveConfig(
        string projectId, string location, string liveConfigId)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        GetLiveConfigRequest request = new GetLiveConfigRequest
        {
            LiveConfigName = LiveConfigName.FromProjectLocationLiveConfig(projectId, location, liveConfigId)
        };

        // Call the API.
        LiveConfig response = client.GetLiveConfig(request);

        // Return the result.
        return response;
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"encoding/json"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// getLiveConfig gets a previously-created live config.
func getLiveConfig(w io.Writer, projectID, liveConfigID string) error {
	// projectID := "my-project-id"
	// liveConfigID := "my-live-config-id"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	req := &stitcherstreampb.GetLiveConfigRequest{
		Name: fmt.Sprintf("projects/%s/locations/%s/liveConfigs/%s", projectID, location, liveConfigID),
	}

	response, err := client.GetLiveConfig(ctx, req)
	if err != nil {
		return fmt.Errorf("client.GetLiveConfig: %w", err)
	}
	b, err := json.MarshalIndent(response, "", " ")
	if err != nil {
		return fmt.Errorf("json.MarshalIndent: %w", err)
	}

	fmt.Fprintf(w, "Live config:\n%s", string(b))
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.GetLiveConfigRequest;
import com.google.cloud.video.stitcher.v1.LiveConfig;
import com.google.cloud.video.stitcher.v1.LiveConfigName;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;

public class GetLiveConfig {

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String liveConfigId = "my-live-config-id";

    getLiveConfig(projectId, location, liveConfigId);
  }

  // Gets a live config.
  public static LiveConfig getLiveConfig(String projectId, String location, String liveConfigId)
      throws IOException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      GetLiveConfigRequest getLiveConfigRequest =
          GetLiveConfigRequest.newBuilder()
              .setName(LiveConfigName.of(projectId, location, liveConfigId).toString())
              .build();

      LiveConfig response = videoStitcherServiceClient.getLiveConfig(getLiveConfigRequest);
      System.out.println("Live config: " + response.getName());
      return response;
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// liveConfigId = 'my-live-config-id';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function getLiveConfig() {
  // Construct request
  const request = {
    name: stitcherClient.liveConfigPath(projectId, location, liveConfigId),
  };
  const [liveConfig] = await stitcherClient.getLiveConfig(request);
  console.log(`Live config: ${liveConfig.name}`);
}

getLiveConfig().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\GetLiveConfigRequest;

/**
 * Gets a live config.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the live config
 * @param string $liveConfigId         The ID of the live config
 */
function get_live_config(
    string $callingProjectId,
    string $location,
    string $liveConfigId
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $formattedName = $stitcherClient->liveConfigName($callingProjectId, $location, $liveConfigId);
    $request = (new GetLiveConfigRequest())
        ->setName($formattedName);
    $liveConfig = $stitcherClient->getLiveConfig($request);

    // Print results
    printf('Live config: %s' . PHP_EOL, $liveConfig->getName());
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video import stitcher_v1
from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)


def get_live_config(
    project_id: str, location: str, live_config_id: str
) -> stitcher_v1.types.LiveConfig:
    """Gets a live config.
    Args:
        project_id: The GCP project ID.
        location: The location of the live config.
        live_config_id: The user-defined live config ID.

    Returns:
        The live config resource.
    """

    client = VideoStitcherServiceClient()

    name = f"projects/{project_id}/locations/{location}/liveConfigs/{live_config_id}"
    response = client.get_live_config(name=name)
    print(f"Live config: {response.name}")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Get a live config
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param live_config_id [String] Your live config name (e.g. `my-live-config`)
#
def get_live_config project_id:, location:, live_config_id:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the live config.
  name = client.live_config_path project: project_id, location: location,
                                 live_config: live_config_id

  # Get the live config.
  live_config = client.get_live_config name: name

  # Print the live config name.
  puts "Live config: #{live_config.name}"
end

检查状态是否设置为 READY。如果不是，请等待几秒钟，然后再次发送请求。

创建会话

如需为拼接广告的视频创建会话，请使用 projects.locations.liveSessions.create 方法。

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：IAM 设置页面上项目编号字段中显示的 Google Cloud 项目编号
LOCATION：用于创建会话的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
LIVE_CONFIG_ID：实时配置的用户定义标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

cat > request.json << 'EOF'
{
  "liveConfig": "projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID"
}
EOF

然后，执行以下命令以发送 REST 请求：

curl -X POST \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     -H "Content-Type: application/json; charset=utf-8" \
     -d @request.json \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveSessions"

PowerShell (Windows)

将请求正文保存在名为 request.json 的文件中。在终端中运行以下命令，在当前目录中创建或覆盖此文件：

@'
{
  "liveConfig": "projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID"
}
'@  | Out-File -FilePath request.json -Encoding utf8

然后，执行以下命令以发送 REST 请求：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method POST `
    -Headers $headers `
    -ContentType: "application/json; charset=utf-8" `
    -InFile request.json `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveSessions" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/liveSessions/SESSION_ID",
  "playUri": "PLAY_URI",
  "liveConfig": "projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID",
}

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Cloud.Video.Stitcher.V1;

public class CreateLiveSessionSample
{
    public LiveSession CreateLiveSession(
        string projectId, string location, string liveConfigId)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        CreateLiveSessionRequest request = new CreateLiveSessionRequest
        {
            Parent = $"projects/{projectId}/locations/{location}",
            LiveSession = new LiveSession
            {
                LiveConfig = LiveConfigName.FormatProjectLocationLiveConfig(projectId, location, liveConfigId)
            }
        };

        // Call the API.
        LiveSession session = client.CreateLiveSession(request);

        // Return the result.
        return session;
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	"cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// createLiveSession creates a livestream session in which to insert ads.
// Live sessions are ephemeral resources that expire after a few minutes.
func createLiveSession(w io.Writer, projectID, liveConfigID string) error {
	// projectID := "my-project-id"
	// liveConfigID := "my-live-config"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	req := &stitcherpb.CreateLiveSessionRequest{
		Parent: fmt.Sprintf("projects/%s/locations/%s", projectID, location),
		LiveSession: &stitcherpb.LiveSession{
			LiveConfig: fmt.Sprintf("projects/%s/locations/%s/liveConfigs/%s", projectID, location, liveConfigID),
		},
	}
	// Creates the live session.
	response, err := client.CreateLiveSession(ctx, req)
	if err != nil {
		return fmt.Errorf("client.CreateLiveSession: %w", err)
	}

	fmt.Fprintf(w, "Live session: %v\n", response.GetName())
	fmt.Fprintf(w, "Play URI: %v", response.GetPlayUri())
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.CreateLiveSessionRequest;
import com.google.cloud.video.stitcher.v1.LiveConfigName;
import com.google.cloud.video.stitcher.v1.LiveSession;
import com.google.cloud.video.stitcher.v1.LocationName;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;

public class CreateLiveSession {

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String liveConfigId = "my-live-config-id";

    createLiveSession(projectId, location, liveConfigId);
  }

  // Creates a live session given the parameters in the supplied live config.
  // For more information, see
  // https://cloud.google.com/video-stitcher/docs/how-to/managing-live-sessions.
  public static LiveSession createLiveSession(
      String projectId, String location, String liveConfigId) throws IOException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      CreateLiveSessionRequest createLiveSessionRequest =
          CreateLiveSessionRequest.newBuilder()
              .setParent(LocationName.of(projectId, location).toString())
              .setLiveSession(
                  LiveSession.newBuilder()
                      .setLiveConfig(LiveConfigName.format(projectId, location, liveConfigId)))
              .build();

      LiveSession response = videoStitcherServiceClient.createLiveSession(createLiveSessionRequest);
      System.out.println("Created live session: " + response.getName());
      System.out.println("Play URI: " + response.getPlayUri());
      return response;
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// liveConfigId = 'my-live-config-id';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function createLiveSession() {
  // Construct request
  const request = {
    parent: stitcherClient.locationPath(projectId, location),
    liveSession: {
      liveConfig: stitcherClient.liveConfigPath(
        projectId,
        location,
        liveConfigId
      ),
    },
  };

  const [session] = await stitcherClient.createLiveSession(request);
  console.log(`Live session: ${session.name}`);
  console.log(`Play URI: ${session.playUri}`);
}

createLiveSession().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\CreateLiveSessionRequest;
use Google\Cloud\Video\Stitcher\V1\LiveSession;

/**
 * Creates a live session. Live sessions are ephemeral resources that expire
 * after a few minutes.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the session
 * @param string $liveConfigId         The live config ID to use to create the
 *                                     live session
 */
function create_live_session(
    string $callingProjectId,
    string $location,
    string $liveConfigId
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $parent = $stitcherClient->locationName($callingProjectId, $location);
    $liveConfig = $stitcherClient->liveConfigName($callingProjectId, $location, $liveConfigId);
    $liveSession = new LiveSession();
    $liveSession->setLiveConfig($liveConfig);

    // Run live session creation request
    $request = (new CreateLiveSessionRequest())
        ->setParent($parent)
        ->setLiveSession($liveSession);
    $response = $stitcherClient->createLiveSession($request);

    // Print results
    printf('Live session: %s' . PHP_EOL, $response->getName());
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video import stitcher_v1
from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)


def create_live_session(
    project_id: str, location: str, live_config_id: str
) -> stitcher_v1.types.LiveSession:
    """Creates a live session. Live sessions are ephemeral resources that expire
    after a few minutes.
    Args:
        project_id: The GCP project ID.
        location: The location in which to create the session.
        live_config_id: The user-defined live config ID.

    Returns:
        The live session resource.
    """

    client = VideoStitcherServiceClient()

    parent = f"projects/{project_id}/locations/{location}"
    live_config = (
        f"projects/{project_id}/locations/{location}/liveConfigs/{live_config_id}"
    )

    live_session = stitcher_v1.types.LiveSession(live_config=live_config)

    response = client.create_live_session(parent=parent, live_session=live_session)
    print(f"Live session: {response.name}")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Create a live stream session. Live sessions are ephemeral resources
# that expire after a few minutes.
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param live_config_id [String] Your live config name (e.g. `my-live-config`)
#
def create_live_session project_id:, location:, live_config_id:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the parent.
  parent = client.location_path project: project_id, location: location

  # Build the resource name of the live config.
  live_config_name = client.live_config_path project: project_id,
                                             location: location,
                                             live_config: live_config_id

  # Set the session fields.
  new_live_session = {
    live_config: live_config_name
  }

  response = client.create_live_session parent: parent,
                                        live_session: new_live_session

  # Print the live session name.
  puts "Live session: #{response.name}"
end

收到响应后，您可以通过引用响应对象的 playUri 字段中的 URI 来播放拼接了广告的直播。

Video Stitcher API 会为每个请求生成唯一的会话 ID。如果在过去 5 分钟内未请求 playUri，会话将过期。

播放拼接了广告的直播

使用响应对象的 playUri 字段中的 URI 播放拼接了广告的直播。如需在 Shaka Player 中播放此直播，请完成以下步骤：

前往在线媒体播放器 Shaka Player。
点击顶部导航栏中的自定义内容。
点击 + 按钮。
将 playUri 字段的值 (PLAY_URI) 粘贴到清单网址框中。
在名称框中输入一个名称。
点击保存。
点击播放。

插入广告插播时间点

Video Stitcher API 会针对每个广告插播时间点插入从广告代码中检索到的广告。广告插播时间点在清单中使用广告标记表示。广告标记由直播编码器插入。如需详细了解支持的 HLS 和 DASH 广告标记，请参阅广告标记文档。

如果您使用 Live Stream API 创建直播，则可以使用频道活动插入广告插播时间。

确认广告已拼接

广告必须先经过编码，然后才能拼接进直播会话。如果您看到的是补位内容视频而不是广告，请等待广告编码，然后插入另一个广告插播时间点。

清理

为避免因本页面中使用的资源导致您的 Google Cloud 账号产生费用，请删除包含这些资源的 Google Cloud 项目。

删除实时配置

如需删除实时配置，请运行以下命令：

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：实时配置的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
LIVE_CONFIG_ID：实时配置的用户定义标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

执行以下命令：

curl -X DELETE \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method DELETE `
    -Headers $headers `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/liveConfigs/LIVE_CONFIG_ID",
    "verb": "delete",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

此命令会创建一个长时间运行的操作 (LRO)，您可以查询该操作以跟踪进度。如需了解详情，请参阅检查结果。

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Cloud.Video.Stitcher.V1;
using Google.LongRunning;
using Google.Protobuf.WellKnownTypes;
using System.Threading.Tasks;

public class DeleteLiveConfigSample
{
    public async Task DeleteLiveConfigAsync(
        string projectId, string location, string liveConfigId)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        DeleteLiveConfigRequest request = new DeleteLiveConfigRequest
        {
            LiveConfigName = LiveConfigName.FromProjectLocationLiveConfig(projectId, location, liveConfigId)
        };

        // Make the request.
        Operation<Empty, OperationMetadata> response = await client.DeleteLiveConfigAsync(request);

        // Poll until the returned long-running operation is complete.
        await response.PollUntilCompletedAsync();
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// deleteLiveConfig deletes a previously-created live config.
func deleteLiveConfig(w io.Writer, projectID, liveConfigID string) error {
	// projectID := "my-project-id"
	// liveConfigID := "my-live-config-id"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	req := &stitcherstreampb.DeleteLiveConfigRequest{
		Name: fmt.Sprintf("projects/%s/locations/%s/liveConfigs/%s", projectID, location, liveConfigID),
	}
	// Deletes the live config.
	op, err := client.DeleteLiveConfig(ctx, req)
	if err != nil {
		return fmt.Errorf("client.DeleteLiveConfig: %w", err)
	}
	err = op.Wait(ctx)
	if err != nil {
		return err
	}

	fmt.Fprintf(w, "Deleted live config")
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.DeleteLiveConfigRequest;
import com.google.cloud.video.stitcher.v1.LiveConfigName;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class DeleteLiveConfig {

  private static final int TIMEOUT_IN_MINUTES = 2;

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String liveConfigId = "my-live-config-id";

    deleteLiveConfig(projectId, location, liveConfigId);
  }

  // Deletes a live config.
  public static void deleteLiveConfig(String projectId, String location, String liveConfigId)
      throws IOException, ExecutionException, InterruptedException, TimeoutException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      DeleteLiveConfigRequest deleteLiveConfigRequest =
          DeleteLiveConfigRequest.newBuilder()
              .setName(LiveConfigName.of(projectId, location, liveConfigId).toString())
              .build();

      videoStitcherServiceClient
          .deleteLiveConfigAsync(deleteLiveConfigRequest)
          .get(TIMEOUT_IN_MINUTES, TimeUnit.MINUTES);
      System.out.println("Deleted live config");
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// liveConfigId = 'my-live-config-id';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function deleteLiveConfig() {
  // Construct request
  const request = {
    name: stitcherClient.liveConfigPath(projectId, location, liveConfigId),
  };
  const [operation] = await stitcherClient.deleteLiveConfig(request);
  await operation.promise();
  console.log('Deleted live config');
}

deleteLiveConfig().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\DeleteLiveConfigRequest;

/**
 * Deletes a live config.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the live config
 * @param string $liveConfigId         The ID of the live config
 */
function delete_live_config(
    string $callingProjectId,
    string $location,
    string $liveConfigId
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $formattedName = $stitcherClient->liveConfigName($callingProjectId, $location, $liveConfigId);
    $request = (new DeleteLiveConfigRequest())
        ->setName($formattedName);
    $operationResponse = $stitcherClient->deleteLiveConfig($request);
    $operationResponse->pollUntilComplete();
    if ($operationResponse->operationSucceeded()) {
        // Print status
        printf('Deleted live config %s' . PHP_EOL, $liveConfigId);
    } else {
        $error = $operationResponse->getError();
        // handleError($error)
    }
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)
from google.protobuf import empty_pb2 as empty


def delete_live_config(
    project_id: str, location: str, live_config_id: str
) -> empty.Empty:
    """Deletes a live config.
    Args:
        project_id: The GCP project ID.
        location: The location of the live config.
        live_config_id: The user-defined live config ID."""

    client = VideoStitcherServiceClient()

    name = f"projects/{project_id}/locations/{location}/liveConfigs/{live_config_id}"
    operation = client.delete_live_config(name=name)
    response = operation.result()
    print("Deleted live config")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Delete a live config
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param live_config_id [String] Your live config name (e.g. `my-live-config`)
#
def delete_live_config project_id:, location:, live_config_id:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the live config.
  name = client.live_config_path project: project_id, location: location,
                                 live_config: live_config_id

  # Delete the live config.
  operation = client.delete_live_config name: name

  # The returned object is of type Gapic::Operation. You can use this
  # object to check the status of an operation, cancel it, or wait
  # for results. Here is how to block until completion:
  operation.wait_until_done!

  # Print a success message.
  puts "Deleted live config"
end

删除补位广告

如需删除平板配置，请运行以下命令：

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：平板电脑所在的位置；请使用其中一个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
SLATE_ID：用户定义的平板标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

执行以下命令：

curl -X DELETE \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method DELETE `
    -Headers $headers `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/slates/SLATE_ID",
    "verb": "delete",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

此命令会创建一个长时间运行的操作 (LRO)，您可以查询该操作以跟踪进度。如需了解详情，请参阅检查结果。

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Cloud.Video.Stitcher.V1;
using Google.LongRunning;
using Google.Protobuf.WellKnownTypes;
using System.Threading.Tasks;

public class DeleteSlateSample
{
    public async Task DeleteSlateAsync(
        string projectId, string location, string slateId)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        DeleteSlateRequest request = new DeleteSlateRequest
        {
            SlateName = SlateName.FromProjectLocationSlate(projectId, location, slateId)
        };

        // Make the request.
        Operation<Empty, OperationMetadata> response = await client.DeleteSlateAsync(request);

        // Poll until the returned long-running operation is complete.
        await response.PollUntilCompletedAsync();
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// deleteSlate deletes a previously-created slate.
func deleteSlate(w io.Writer, projectID, slateID string) error {
	// projectID := "my-project-id"
	// slateID := "my-slate-id"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	name := fmt.Sprintf("projects/%s/locations/%s/slates/%s", projectID, location, slateID)

	req := &stitcherstreampb.DeleteSlateRequest{
		Name: name,
	}
	// Deletes the slate.
	op, err := client.DeleteSlate(ctx, req)
	if err != nil {
		return fmt.Errorf("client.DeleteSlate: %w", err)
	}
	err = op.Wait(ctx)
	if err != nil {
		return err
	}

	fmt.Fprintf(w, "Deleted slate")
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.DeleteSlateRequest;
import com.google.cloud.video.stitcher.v1.SlateName;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class DeleteSlate {

  private static final int TIMEOUT_IN_MINUTES = 2;

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String slateId = "my-slate-id";

    deleteSlate(projectId, location, slateId);
  }

  // Deletes a slate.
  public static void deleteSlate(String projectId, String location, String slateId)
      throws IOException, ExecutionException, InterruptedException, TimeoutException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      DeleteSlateRequest deleteSlateRequest =
          DeleteSlateRequest.newBuilder()
              .setName(SlateName.of(projectId, location, slateId).toString())
              .build();

      videoStitcherServiceClient
          .deleteSlateAsync(deleteSlateRequest)
          .get(TIMEOUT_IN_MINUTES, TimeUnit.MINUTES);
      System.out.println("Deleted slate");
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// slateId = 'my-slate';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function deleteSlate() {
  // Construct request
  const request = {
    name: stitcherClient.slatePath(projectId, location, slateId),
  };
  const [operation] = await stitcherClient.deleteSlate(request);
  await operation.promise();
  console.log('Deleted slate');
}

deleteSlate().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\DeleteSlateRequest;

/**
 * Deletes a slate.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the slate
 * @param string $slateId              The ID of the slate
 */
function delete_slate(
    string $callingProjectId,
    string $location,
    string $slateId
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $formattedName = $stitcherClient->slateName($callingProjectId, $location, $slateId);
    $request = (new DeleteSlateRequest())
        ->setName($formattedName);
    $operationResponse = $stitcherClient->deleteSlate($request);
    $operationResponse->pollUntilComplete();
    if ($operationResponse->operationSucceeded()) {
        // Print status
        printf('Deleted slate %s' . PHP_EOL, $slateId);
    } else {
        $error = $operationResponse->getError();
        // handleError($error)
    }
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)
from google.protobuf import empty_pb2 as empty


def delete_slate(project_id: str, location: str, slate_id: str) -> empty.Empty:
    """Deletes a slate.
    Args:
        project_id: The GCP project ID.
        location: The location of the slate.
        slate_id: The user-defined slate ID."""

    client = VideoStitcherServiceClient()

    name = f"projects/{project_id}/locations/{location}/slates/{slate_id}"
    operation = client.delete_slate(name=name)
    response = operation.result()
    print("Deleted slate")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Delete a slate
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param slate_id [String] Your slate name (e.g. `my-slate`)
#
def delete_slate project_id:, location:, slate_id:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the slate.
  name = client.slate_path project: project_id, location: location,
                           slate: slate_id

  # Delete the slate.
  operation = client.delete_slate name: name

  # The returned object is of type Gapic::Operation. You can use this
  # object to check the status of an operation, cancel it, or wait
  # for results. Here is how to block until completion:
  operation.wait_until_done!

  # Print a success message.
  puts "Deleted slate"
end

删除 CDN 密钥

如需删除 CDN 密钥，请运行以下命令：

REST

在使用任何请求数据之前，请先进行以下替换：

PROJECT_NUMBER：您的 Google Cloud 项目编号；该编号位于 IAM 设置页面上的项目编号字段中
LOCATION：CDN 密钥所在的位置；请使用某个受支持的地区
显示位置
- us-central1
- us-east1
- us-west1
- asia-east1
- asia-south1
- asia-southeast1
- europe-west1
- southamerica-east1
CDN_KEY_ID：用户定义的 CDN 密钥标识符

如需发送您的请求，请展开以下选项之一：

curl（Linux、macOS 或 Cloud Shell）

执行以下命令：

curl -X DELETE \
     -H "Authorization: Bearer $(gcloud auth print-access-token)" \
     "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID"

PowerShell (Windows)

注意：以下命令假定您已使用您的用户账号通过运行 gcloud init 或 gcloud auth login 登录 gcloud CLI。您可以运行 gcloud auth list 来检查当前活跃的账号。

执行以下命令：

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred" }

Invoke-WebRequest `
    -Method DELETE `
    -Headers $headers `
    -Uri "https://videostitcher.googleapis.com/v1/projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID" | Select-Object -Expand Content

您应该收到类似以下内容的 JSON 响应：

{
  "name": "projects/PROJECT_NUMBER/locations/LOCATION/operations/OPERATION_ID",
  "metadata": {
    "@type": "type.googleapis.com/google.cloud.common.OperationMetadata",
    "createTime": CREATE_TIME,
    "target": "projects/PROJECT_NUMBER/locations/LOCATION/cdnKeys/CDN_KEY_ID",
    "verb": "delete",
    "cancelRequested": false,
    "apiVersion": "v1"
  },
  "done": false
}

此命令会创建一个长时间运行的操作 (LRO)，您可以查询该操作以跟踪进度。如需了解详情，请参阅检查结果。

C#

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


using Google.Cloud.Video.Stitcher.V1;
using Google.LongRunning;
using Google.Protobuf.WellKnownTypes;
using System.Threading.Tasks;

public class DeleteCdnKeySample
{
    public async Task DeleteCdnKeyAsync(
        string projectId, string location, string cdnKeyId)
    {
        // Create the client.
        VideoStitcherServiceClient client = VideoStitcherServiceClient.Create();

        DeleteCdnKeyRequest request = new DeleteCdnKeyRequest
        {
            CdnKeyName = CdnKeyName.FromProjectLocationCdnKey(projectId, location, cdnKeyId)
        };

        // Make the request.
        Operation<Empty, OperationMetadata> response = await client.DeleteCdnKeyAsync(request);

        // Poll until the returned long-running operation is complete.
        await response.PollUntilCompletedAsync();
    }
}

Go

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

import (
	"context"
	"fmt"
	"io"

	stitcher "cloud.google.com/go/video/stitcher/apiv1"
	stitcherstreampb "cloud.google.com/go/video/stitcher/apiv1/stitcherpb"
)

// deleteCDNKey deletes a CDN key.
func deleteCDNKey(w io.Writer, projectID, keyID string) error {
	// projectID := "my-project-id"
	// keyID := "my-cdn-key"
	location := "us-central1"
	ctx := context.Background()
	client, err := stitcher.NewVideoStitcherClient(ctx)
	if err != nil {
		return fmt.Errorf("stitcher.NewVideoStitcherClient: %w", err)
	}
	defer client.Close()

	name := fmt.Sprintf("projects/%s/locations/%s/cdnKeys/%s", projectID, location, keyID)

	req := &stitcherstreampb.DeleteCdnKeyRequest{
		Name: name,
	}
	// Deletes the CDN key.
	op, err := client.DeleteCdnKey(ctx, req)
	if err != nil {
		return fmt.Errorf("client.DeleteCdnKey: %w", err)
	}
	err = op.Wait(ctx)
	if err != nil {
		return err
	}

	fmt.Fprintf(w, "Deleted CDN key")
	return nil
}

Java

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import com.google.cloud.video.stitcher.v1.CdnKeyName;
import com.google.cloud.video.stitcher.v1.DeleteCdnKeyRequest;
import com.google.cloud.video.stitcher.v1.VideoStitcherServiceClient;
import java.io.IOException;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class DeleteCdnKey {

  private static final int TIMEOUT_IN_MINUTES = 2;

  public static void main(String[] args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "my-project-id";
    String location = "us-central1";
    String cdnKeyId = "my-cdn-key-id";

    deleteCdnKey(projectId, location, cdnKeyId);
  }

  // Deletes a CDN key.
  public static void deleteCdnKey(String projectId, String location, String cdnKeyId)
      throws InterruptedException, ExecutionException, TimeoutException, IOException {
    // Initialize client that will be used to send requests. This client only needs to be created
    // once, and can be reused for multiple requests.
    try (VideoStitcherServiceClient videoStitcherServiceClient =
        VideoStitcherServiceClient.create()) {
      DeleteCdnKeyRequest deleteCdnKeyRequest =
          DeleteCdnKeyRequest.newBuilder()
              .setName(CdnKeyName.of(projectId, location, cdnKeyId).toString())
              .build();

      videoStitcherServiceClient
          .deleteCdnKeyAsync(deleteCdnKeyRequest)
          .get(TIMEOUT_IN_MINUTES, TimeUnit.MINUTES);
      System.out.println("Deleted CDN key");
    }
  }
}

Node.js

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// projectId = 'my-project-id';
// location = 'us-central1';
// cdnKeyId = 'my-cdn-key';

// Imports the Video Stitcher library
const {VideoStitcherServiceClient} =
  require('@google-cloud/video-stitcher').v1;
// Instantiates a client
const stitcherClient = new VideoStitcherServiceClient();

async function deleteCdnKey() {
  // Construct request
  const request = {
    name: stitcherClient.cdnKeyPath(projectId, location, cdnKeyId),
  };
  const [operation] = await stitcherClient.deleteCdnKey(request);
  await operation.promise();
  console.log('Deleted CDN key');
}

deleteCdnKey().catch(err => {
  console.error(err.message);
  process.exitCode = 1;
});

PHP

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

use Google\Cloud\Video\Stitcher\V1\Client\VideoStitcherServiceClient;
use Google\Cloud\Video\Stitcher\V1\DeleteCdnKeyRequest;

/**
 * Deletes a CDN key.
 *
 * @param string $callingProjectId     The project ID to run the API call under
 * @param string $location             The location of the CDN key
 * @param string $cdnKeyId             The ID of the CDN key
 */
function delete_cdn_key(
    string $callingProjectId,
    string $location,
    string $cdnKeyId
): void {
    // Instantiate a client.
    $stitcherClient = new VideoStitcherServiceClient();

    $formattedName = $stitcherClient->cdnKeyName($callingProjectId, $location, $cdnKeyId);
    $request = (new DeleteCdnKeyRequest())
        ->setName($formattedName);
    $operationResponse = $stitcherClient->deleteCdnKey($request);
    $operationResponse->pollUntilComplete();
    if ($operationResponse->operationSucceeded()) {
        // Print status
        printf('Deleted CDN key %s' . PHP_EOL, $cdnKeyId);
    } else {
        $error = $operationResponse->getError();
        // handleError($error)
    }
}

Python

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。


import argparse

from google.cloud.video.stitcher_v1.services.video_stitcher_service import (
    VideoStitcherServiceClient,
)
from google.protobuf import empty_pb2 as empty


def delete_cdn_key(project_id: str, location: str, cdn_key_id: str) -> empty.Empty:
    """Deletes a CDN key.
    Args:
        project_id: The GCP project ID.
        location: The location of the CDN key.
        cdn_key_id: The user-defined CDN key ID."""

    client = VideoStitcherServiceClient()

    name = f"projects/{project_id}/locations/{location}/cdnKeys/{cdn_key_id}"
    operation = client.delete_cdn_key(name=name)
    response = operation.result()
    print("Deleted CDN key")
    return response

Ruby

如需向 Video Stitcher API 进行身份验证，请设置应用默认凭据。如需了解详情，请参阅为本地开发环境设置身份验证。

require "google/cloud/video/stitcher"

##
# Delete a CDN key
#
# @param project_id [String] Your Google Cloud project (e.g. `my-project`)
# @param location [String] The location (e.g. `us-central1`)
# @param cdn_key_id [String] Your CDN key name (e.g. `my-cdn-key`)
#
def delete_cdn_key project_id:, location:, cdn_key_id:
  # Create a Video Stitcher client.
  client = Google::Cloud::Video::Stitcher.video_stitcher_service

  # Build the resource name of the CDN key.
  name = client.cdn_key_path project: project_id, location: location,
                             cdn_key: cdn_key_id

  # Delete the CDN key.
  operation = client.delete_cdn_key name: name

  # The returned object is of type Gapic::Operation. You can use this
  # object to check the status of an operation, cancel it, or wait
  # for results. Here is how to block until completion:
  operation.wait_until_done!

  # Print a success message.
  puts "Deleted CDN key"
end

撤消您的凭据

可选：撤消您创建的身份验证凭据，并删除本地凭据文件。
```
gcloud auth application-default revoke
```
可选：从 gcloud CLI 撤消凭据。
```
gcloud auth revoke
```

后续步骤

查看 Video Stitcher API 参考文档。
